OSRAM Chip LED, CT ELLN51.14
|
With enhanced brightness, the CT ELLN51.14 ensures more precise heart rate measurements. Its ultra-compact design is perfect for space-constrained wearables such as rings and in-ear headphones.
Additionally, its increased efficiency extends battery life at system level.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.048 W
|
Low
|
14 mW
|
-40 °C
|
85 °C
|
1.2 mm
|
1.0 mm
|
0.6 mm
|
|
OSRAM OSCONIQ™ P 3737 (2W), GD PUBRA1.15
|
OSCONIQ™ P 3737 Batwing delivers exceptional light
uniformity, enhanced brightness and long lifetime. Featuring a unique batwing radiation profile, it ensures wide-angle coverage with reduced hotspots, making it ideal for large-area horticultural lighting. Available in a range of targeted wavelengths, the P 3737 Batwing offers design flexibility and spectral precision to meet the dynamic needs of modern growers.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
2.0 W
|
High
|
140 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
|
OSRAM OSCONIQ™ P 3737 (2W), GF PUBRA1.25
|
OSCONIQ™ P 3737 Batwing delivers exceptional light
uniformity, enhanced brightness and long lifetime. Featuring a unique batwing radiation profile, it ensures wide-angle coverage with reduced hotspots, making it ideal for large-area horticultural lighting. Available in a range of targeted wavelengths, the P 3737 Batwing offers design flexibility and spectral precision to meet the dynamic needs of modern growers.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
1.2 W
|
High
|
0.00533 lm
|
0.00159 cd
|
4.46 mW
|
1.34 mW/sr
|
140 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
0.0000327 µmol/s
|
|
OSRAM OSCONIQ™ P 3737 (2W), GH PUBRA1.25
|
OSCONIQ™ P 3737 Batwing delivers exceptional light
uniformity, enhanced brightness and long lifetime. Featuring a unique batwing radiation profile, it ensures wide-angle coverage with reduced hotspots, making it ideal for large-area horticultural lighting. Available in a range of targeted wavelengths, the P 3737 Batwing offers design flexibility and spectral precision to meet the dynamic needs of modern growers.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
1.3 W
|
High
|
34.4 lm
|
9.76 cd
|
1050 mW
|
299 mW/sr
|
140 °
|
-40 °C
|
125 °C
|
5.9 µmol/s
|
|
OSRAM OSCONIQ™ P 3737 (2W), GW PUBRA1.HW
|
OSCONIQ™ P 3737 Batwing delivers exceptional light
uniformity, enhanced brightness and long lifetime. Featuring a unique batwing radiation profile, it ensures wide-angle coverage with reduced hotspots, making it ideal for large-area horticultural lighting. Available in a range of targeted wavelengths, the P 3737 Batwing offers design flexibility and spectral precision to meet the dynamic needs of modern growers.
|
LEDs
|
Color LEDs
|
White
|
2.0 W
|
High
|
140 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
|
OSRAM SYNIOS™ P2222, KB DDLN31.13
|
The SYNIOS™ P2222 is the new standard mid-power LED for Automotive Signaling applications. It features a small package outline and is available in all application-specific colors.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
12.6 lm
|
3.94 cd
|
370 mW
|
116 mW/sr
|
-40 °C
|
125 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
0.0475 µmol/s
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2222, KY DDLN31.FY
|
The SYNIOS™ P2222 is the new standard mid-power LED for Automotive Signaling applications. It features a small package outline and is available in all application-specific colors.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.49 W
|
Mid
|
36.5 lm
|
12.5 cd
|
113 mW
|
38.9 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
0.188 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LA E6SF.01
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
11.2 lm
|
3.75 cd
|
46.6 mW
|
15.6 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0195 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LA ETSF.01
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
11.2 lm
|
3.75 cd
|
46.6 mW
|
15.6 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0195 µmol/s
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE A Q7WN
|
The OSTAR Projection LE A Q7WN is specifically designed for automotive head-up applications using a DMD.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
2.4 W
|
High
|
290 lm
|
104 cd
|
1200 mW
|
430 mW/sr
|
120 °
|
-40 °C
|
105 °C
|
5.77 mm
|
4.7 mm
|
1.25 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE B Q7WN
|
The OSTAR Projection LE B Q7WN is specifically designed for automotive head-up applications using a DMD.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
3.0 W
|
High
|
137 lm
|
47.2 cd
|
3120 mW
|
1070 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
5.77 mm
|
4.7 mm
|
1.25 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE CG Q7WN
|
The OSTAR Projection LE CG Q7WN is specifically designed for automotive head-up applications using a DMD.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
3.0 W
|
High
|
960 lm
|
218 cd
|
2100 mW
|
477 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
5.77 mm
|
4.77 mm
|
1.25 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Stage, LE R S2WP
|
Outstanding brightness and luminance due to surface emission and low Rth
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
3.0 W
|
High
|
0.75 lm
|
120 °
|
-40 °C
|
85 °C
|
6.38 mm
|
5.75 mm
|
1.26 mm
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE T Q7WN
|
The OSTAR Projection LE T Q7WN is specifically designed for automotive head-up applications using a DMD.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
2.9 W
|
High
|
540 lm
|
179 cd
|
1140 mW
|
377 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
5.77 mm
|
4.7 mm
|
1.25 mm
|
2.37 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LR E6SF.01
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.11 W
|
Low
|
7.74 lm
|
2.53 cd
|
37.6 mW
|
12.3 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0133 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LR ETSF.01
|
PowerTOPLED, a powerful member of the TOPLED
family. Thanks to their high luminous efficacy, the
LEDs are ideal for rear light clusters and indicators
on vehicles and for display panels for traffic control
systems.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.11 W
|
Low
|
10.3 lm
|
3.37 cd
|
50.1 mW
|
16.4 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0177 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LS E6SF.01
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.11 W
|
Low
|
7.54 lm
|
2.47 cd
|
58.1 mW
|
19.1 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LS ETSF.01
|
PowerTOPLED, a powerful member of the TOPLED
family. Thanks to their high luminous efficacy, the
LEDs are ideal for rear light clusters and indicators
on vehicles and for display panels for traffic control
systems.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.11 W
|
Low
|
7.57 lm
|
2.47 cd
|
59.6 mW
|
19.5 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0133 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LY E6SF.01
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
10.3 lm
|
3.37 cd
|
20.7 mW
|
6.8 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LY ETSF.01
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
9.9 lm
|
3.37 cd
|
19.8 mW
|
6.73 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0167 µmol/s
|
AEC-Q102
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00R208
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
6.4 W
|
Ultra High
|
254 lm
|
117 cd
|
3400 mW
|
1560 mW/sr
|
100 °
|
-40 °C
|
125 °C
|
7.0 mm
|
7.0 mm
|
3.7 mm
|
18.5 µmol/s
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-01R308
|
Industry's most robust high power ceramic package with silicone flat top for high performance over life.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
6.0 W
|
2.75 lm
|
0.812 cd
|
1860 mW
|
549 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
7.0 mm
|
7.0 mm
|
1.1 mm
|
11.3 µmol/s
|
|
OSRAM DURIS™ E 2835, GA JTLPS1.23
|
The DURIS™ E 2835 color family provide excellent color rendering and supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.35 W
|
Mid
|
34.5 lm
|
11.1 cd
|
158 mW
|
50.9 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM OSCONIQ™ P 3737 (2W), GD PUSRA2.15
|
Brand new, upgraded high-power LED with our ams OSRAM’s latest chip technology and new generation of optimized lens, delivering industry leading performance, superior robustness and long lifetime. With high efficiency REDS available in three wavelengths, the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
2.0 W
|
High
|
39.3 lm
|
11.9 cd
|
1480 mW
|
446 mW/sr
|
125 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.37 mm
|
5.5 µmol/s
|
|
OSRAM OSCONIQ™ P 3737 (2W), GF PUSRA3.25
|
Brand new, upgraded high-power LED with our ams OSRAM’s latest chip technology and new generation of optimized lens, delivering industry leading performance, superior robustness and long lifetime. With high efficiency REDS available in three wavelengths, the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
1.2 W
|
High
|
1.05 lm
|
0.313 cd
|
878 mW
|
263 mW/sr
|
125 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.37 mm
|
5.4 µmol/s
|
|
OSRAM OSCONIQ™ P 3737 (2W), GH PUSRA2.25
|
Brand new, upgraded high-power LED with our ams OSRAM’s latest chip technology and new generation of optimized lens, delivering industry leading performance, superior robustness and long lifetime. With high efficiency REDS available in three wavelengths, the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
1.3 W
|
High
|
29.1 lm
|
8.64 cd
|
1070 mW
|
317 mW/sr
|
125 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.37 mm
|
6 µmol/s
|
|
OSRAM DURIS™ E 2835, GW JTLPS1.1B
|
The DURIS™ E 2835 color family provide excellent color rendering and supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
0.47 W
|
Mid
|
98 lm
|
31.7 cd
|
448 mW
|
145 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM DURIS™ E 2835, GW JTLPS1.1L
|
The DURIS™ E 2835 color family provide excellent color rendering and supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.47 W
|
Mid
|
106 lm
|
35.5 cd
|
229 mW
|
76.7 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM OSCONIQ™ P 3737 (2W), GW PUSRA2.HW
|
Brand new, upgraded high-power LED with our ams OSRAM’s latest chip technology and new generation of optimized lens, delivering industry leading performance, superior robustness and long lifetime. With high efficiency REDS available in three wavelengths, the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
|
LEDs
|
Color LEDs
|
White
|
2.0 W
|
High
|
402 lm
|
132 cd
|
1190 mW
|
390 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
5.25 µmol/s
|
|
OSRAM DURIS™ E 2835, GY JTLPS1.13
|
The DURIS™ E 2835 color family provide excellent color rendering and supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.47 W
|
Mid
|
68 lm
|
23.2 cd
|
201 mW
|
68.7 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE A P1MS
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
22.0 W
|
Ultra High
|
1430 lm
|
473 cd
|
5460 mW
|
1810 mW/sr
|
120 °
|
7.6 mm
|
6.8 mm
|
1.4 mm
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE B P1MS
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
45.0 W
|
Ultra High
|
351 lm
|
115 cd
|
9030 mW
|
2950 mW/sr
|
120 °
|
7.6 mm
|
6.8 mm
|
1.4 mm
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE CG P1AS
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
44.0 W
|
Ultra High
|
3350 lm
|
1090 cd
|
7290 mW
|
2370 mW/sr
|
120 °
|
7.6 mm
|
6.8 mm
|
1.4 mm
|
|
OSRAM FIREFLY™ E1608, CH DELSS1.22
|
The FIREFLY E1608 family expands ams OSRAM's portfolio of visible products for use in mobile devices like fitness tracking or health monitoring.
It offers one of the smallest LED footprints in a highly reliable and proven package. The compact size of only 0.8 mm x 1.6 mm x 0.6 mm allows customers the benefit of more flexible product designs. The hyper red CH DELSS1.22 is specially designed for SPO2 applications. It features a special narrow wavelength of 655 nm to improve signal detection, that is ideally matched to these applications.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
0.038 W
|
Low
|
0.928 lm
|
0.282 cd
|
16.3 mW
|
4.95 mW/sr
|
120 °
|
-40 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
|
OSRAM FIREFLY™, CT DBLP31.12
|
The FIREFLY E2218 family expands ams OSRAM's portfolio of visible products for use in mobile devices like fitness tracking or health monitoring. It offers the highest efficiency output and lowest forward Voltage (Vf) operation, for longer battery life in portable applications. The compact size
of only 1.8 mm x 2.2 mm x 0.6 mm allows customers the benefit of more flexible product designs. The true green CT DBLP31.12 is specially designed for Heart Rate Monitor applications. It features a very high luminous intensity to ideally match these applications.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.046 W
|
Low
|
4.08 cd
|
120 °
|
-40 °C
|
85 °C
|
2.2 mm
|
1.8 mm
|
0.6 mm
|
|
OSRAM FIREFLY™, CT DBLP32.12
|
The FIREFLY E2218 family expands ams OSRAM's portfolio of visible products for use in mobile devices like fitness tracking or health monitoring. It offers the highest efficiency output and lowest forward Voltage (Vf) operation, for longer battery life in portable applications. The compact size
of only 1.8 mm x 2.2 mm x 0.6 mm allows customers the benefit of more flexible product designs. The true green CT DBLP32.12 is specially designed for Heart Rate Monitor applications. It features a very high luminous intensity to ideally match these applications.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.046 W
|
Low
|
120 °
|
-40 °C
|
85 °C
|
2.2 mm
|
1.8 mm
|
0.6 mm
|
|
OSRAM FIREFLY™ E1608, CT DELSS1.12
|
The FIREFLY E1608 family expands ams OSRAM's portfolio of visible products for use in mobile devices like fitness tracking or health monitoring.
It offers one of the smallest LED footprints in a highly reliable and proven package. The compact size of only 0.8 mm x 1.6 mm x 0.6 mm allows customers the benefit of more flexible product designs. The true green CT DELSS1.22 is specially designed for Heart Rate Monitor applications.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.052 W
|
Low
|
6.04 lm
|
1.96 cd
|
11.8 mW
|
3.82 mW/sr
|
120 °
|
-40 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
|
OSRAM OSLON™ SSL 80, GA CS8PM1.23
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.74 W
|
High
|
87 lm
|
52.3 cd
|
367 mW
|
221 mW/sr
|
80 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.21 mm
|
|
OSRAM OSLON™ SSL 150, GA CSHPM1.23
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.74 W
|
High
|
122 lm
|
25.2 cd
|
514 mW
|
106 mW/sr
|
150 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.51 mm
|
|
OSRAM OSLON™ SSL 120, GA CSSPM1.23
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.74 W
|
High
|
100 lm
|
30 cd
|
422 mW
|
127 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.75 mm
|
|
OSRAM DURIS™ S 5, GA PSLM31.23
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.21 W
|
Mid
|
22.6 lm
|
7.34 cd
|
90.1 mW
|
29.2 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM DURIS™ S 5, GA PSLR31.13
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.94 W
|
High
|
53 lm
|
16.3 cd
|
305 mW
|
93.7 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM OSCONIQ™ P 3030, GA QSSPA1.23
|
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.76 W
|
High
|
119 lm
|
33.6 cd
|
467 mW
|
132 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM OSLON™ SSL 80, GB CS8PM1.13
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
1.0 W
|
High
|
40 lm
|
22.8 cd
|
591 mW
|
338 mW/sr
|
80 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.21 mm
|
|
OSRAM OSLON™ SSL 150, GB CSHPM1.13
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
1.0 W
|
High
|
41 lm
|
9.66 cd
|
606 mW
|
143 mW/sr
|
150 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.44 mm
|
|
OSRAM OSCONIQ™ P 2226, GB DASPA2.13
|
High-efficacy mid-power LED with long lifetimes also at high currents and high junction temperatures.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.29 W
|
Mid
|
7.6 lm
|
2.55 cd
|
113 mW
|
37.8 mW/sr
|
110 °
|
-40 °C
|
120 °C
|
2.6 mm
|
2.2 mm
|
1.25 mm
|
|
OSRAM DURIS™ E 2835, GB JTLPS1.13
|
The DURIS™ E 2835 color family provide supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.48 W
|
Mid
|
15 lm
|
4.81 cd
|
274 mW
|
87.9 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM DURIS™ S 5, GB PSLM31.13
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.29 W
|
Mid
|
10.3 lm
|
3.4 cd
|
153 mW
|
50.4 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM OSCONIQ™ P 3030, GB QSSPA1.13
|
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
1.0 W
|
High
|
42.5 lm
|
13.4 cd
|
628 mW
|
198 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.63 mm
|
0.166 µmol/s
|
|
OSRAM OSLON™ Pure 1414, GB VJLPL1.13
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
1.0 W
|
High
|
42.5 lm
|
14.5 cd
|
74.7 mW
|
25.5 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
1.0 mm
|
|
OSRAM OSLON™ Pure 1414, GB VJLPL1.F3
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
1.0 W
|
High
|
59.5 lm
|
19.7 cd
|
109 mW
|
36.3 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
1.0 mm
|
|
OSRAM OSLON™ Pure 1414, GC VJLPL1.13
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Cyan (482-492 nm)
|
0.96 W
|
High
|
85 lm
|
29 cd
|
479 mW
|
164 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.75 mm
|
|
OSRAM OSLON™ SSL 80, GD CS8PM1.14
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
1.0 W
|
High
|
23.4 lm
|
13.4 cd
|
690 mW
|
394 mW/sr
|
80 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.21 mm
|
|
OSRAM OSLON™ SSL 150, GD CSHPM1.14
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
1.0 W
|
High
|
23.4 lm
|
5.52 cd
|
690 mW
|
163 mW/sr
|
150 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.44 mm
|
|
OSRAM OSLON™ SSL 120, GD CSSPM1.14
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
1.0 W
|
High
|
23.4 lm
|
7.18 cd
|
690 mW
|
211 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.21 mm
|
|
OSRAM OSLON™ Square, GD CSSRM3.14
|
New generation of OSLON Square Deep Blue offers higher brightness with low thermal resistance even when driven at high currents. High reliability. Long lifetime.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
2.0 W
|
High
|
1070 lm
|
327 cd
|
1630 mW
|
497 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.09 mm
|
|
OSRAM OSCONIQ™ P 2226, GD DASPA2.14
|
High-efficacy mid-power LED with long lifetimes also at high currents and high junction temperatures.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
0.29 W
|
Mid
|
5.5 lm
|
1.88 cd
|
166 mW
|
56.8 mW/sr
|
110 °
|
-40 °C
|
120 °C
|
2.6 mm
|
2.2 mm
|
1.25 mm
|
|
OSRAM DURIS™ E 2835, GD JTLPS1.14
|
The DURIS™ E 2835 color family provide excellent supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
0.44 W
|
Mid
|
10.7 lm
|
3.5 cd
|
315 mW
|
103 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM DURIS™ S 5, GD PSLM31.14
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
0.29 W
|
Mid
|
5.97 lm
|
1.98 cd
|
180 mW
|
59.6 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM DURIS™ S 5, GD PSLR31.13
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
0.94 W
|
High
|
14.5 lm
|
4.45 cd
|
540 mW
|
166 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM OSCONIQ™ P 3737 (2W), GD PUSRA1.15
|
High-power LED with our ams OSRAM’s latest chip technology, delivering industry leading performance, superior robustness and long lifetime. With the introduction of a new color
(Red 640 nm) the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
The OSCONIQ™ P 3737 family offers Hyper Red (660 nm), Red (640nm), Deep Blue (450 nm), Far Red (730 nm) and Horti White which can cater to both narrow spectrum and full
spectrum solutions to meet all crop needs for both greenhouses and vertical farms.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
2.0 W
|
High
|
39.3 lm
|
12 cd
|
1480 mW
|
448 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
5.5 µmol/s
|
|
OSRAM OSCONIQ™ P 3030, GD QSSPA1.14
|
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
1.0 W
|
High
|
25.2 lm
|
7.48 cd
|
743 mW
|
220 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.63 mm
|
|
OSRAM OSLON™ Pure 1414, GD VJLPL1.14
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
1.0 W
|
High
|
21.7 lm
|
7.43 cd
|
650 mW
|
223 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.75 mm
|
|
OSRAM OSLON™ Square, GF CSBPM2.24
|
A new member of the family, OSLON™ Square Far Red has a unique innovative radiation pattern to illuminate plants evenly for uniform growth while reducing number of luminaires and lowering overall cost. Additionally, this high-power LED provides excellent reliability, long lifetime and low thermal resistance in a compact footprint.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
0.64 W
|
Mid
|
0.667 lm
|
0.0829 cd
|
433 mW
|
53.7 mW/sr
|
135 °
|
-40 °C
|
120 °C
|
3.1 mm
|
3.1 mm
|
1.58 mm
|
|
OSRAM OSLON™ Optimal, GF CSSRML.24
|
A brand new family of LEDs with our ams OSRAM’s latest chip technology, delivering significant performance upgrades. The OSLON™ Optimal strikes a perfect balance of performance and cost along with proven robustness, high reliability and long lifetime.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
0.64 W
|
Mid
|
0.474 lm
|
0.154 cd
|
473 mW
|
154 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.17 mm
|
|
OSRAM DURIS™ E 2835, GF JTLPS1.24
|
The DURIS™ E 2835 color family provide excellent color rendering and supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
0.29 W
|
Mid
|
0.277 lm
|
0.09 cd
|
110 mW
|
35.8 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM OSCONIQ™ P 3737 (2W), GF PUSRA1.25
|
High-power LED with our ams OSRAM’s latest chip technology, delivering industry leading performance, superior robustness and long lifetime. With the introduction of a new color (Red 640 nm) the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
The OSCONIQ™ P 3737 family offers Hyper Red (660 nm), Red (640nm), Deep Blue (450 nm), Far Red (730 nm) and Horti White which can cater to both narrow spectrum and full spectrum solutions to meet all crop needs for both greenhouses and vertical farms.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
1.4 W
|
High
|
0.97 lm
|
0.29 cd
|
813 mW
|
243 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
5 µmol/s
|
|
OSRAM OSCONIQ™ P 3737 (2W), GF PUSRA2.25
|
High-power LED with our ams OSRAM’s latest chip technology, delivering industry leading performance, superior robustness and long lifetime. With the introduction of a new color
(Red 640 nm) the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
The OSCONIQ™ P 3737 family offers Hyper Red (660 nm), Red (640nm), Deep Blue (450 nm), Far Red (730 nm) and Horti White which can cater to both narrow spectrum and full
spectrum solutions to meet all crop needs for both greenhouses and vertical farms.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
1.2 W
|
High
|
0.97 lm
|
0.272 cd
|
620 mW
|
174 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
0.00595 µmol/s
|
|
OSRAM OSLON™ SSL 80, GH CS8PM1.24
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
0.72 W
|
High
|
28 lm
|
15.3 cd
|
425 mW
|
232 mW/sr
|
80 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.36 mm
|
|
OSRAM OSLON™ SSL 120, GH CSSPM1.24
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
0.72 W
|
High
|
28 lm
|
9.34 cd
|
425 mW
|
142 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.88 mm
|
|
OSRAM OSLON™ Square, GH CSSRM6.24
|
OSLON™ Square Hyper Red with best value for highest PF/W. Most compact high-power LED with proven robustness, high reliability, long lifetime and low thermal resistance.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
1.4 W
|
High
|
68.3 lm
|
21.4 cd
|
1100 mW
|
345 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.17 mm
|
|
OSRAM DURIS™ E 2835, GH JTLPS1.24
|
The DURIS™ E 2835 color family provide excellent color rendering and supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
0.33 W
|
Mid
|
8.93 lm
|
2.87 cd
|
165 mW
|
53 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
0.909 µmol/s
|
|
OSRAM OSCONIQ™ P 3737 (2W), GH PUSRA1.25
|
High-power LED with our ams OSRAM’s latest chip technology, delivering industry leading performance, superior robustness and long lifetime. With the introduction of a new color (Red 640 nm) the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
The OSCONIQ™ P 3737 family offers Hyper Red (660 nm), Red (640nm), Deep Blue (450 nm), Far Red (730 nm) and Horti White which can cater to both narrow spectrum and full spectrum solutions to meet all crop needs for both greenhouses and vertical farms.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
1.3 W
|
High
|
34.6 lm
|
9.8 cd
|
1060 mW
|
300 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
5.92 µmol/s
|
|
OSRAM OSCONIQ™ P 3030, GH QSSPA1.24
|
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
0.74 W
|
High
|
31.6 lm
|
9.13 cd
|
480 mW
|
139 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.73 mm
|
|
OSRAM DURIS™ E 2835, GP JTLPS1.14
|
The DURIS™ E 2835 color family provide supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Purple
|
0.44 W
|
Mid
|
21 lm
|
6.79 cd
|
240 mW
|
77.6 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM DURIS™ S 5, GP PSLM31.14
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Purple
|
0.28 W
|
Mid
|
15.7 lm
|
5.17 cd
|
126 mW
|
41.4 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM DURIS™ S 5, GP PSLR31.14
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Purple
|
0.94 W
|
High
|
42.5 lm
|
13.9 cd
|
340 mW
|
112 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM OSLON™ SSL 80, GR CS8PM1.23
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.74 W
|
High
|
68 lm
|
38.9 cd
|
369 mW
|
211 mW/sr
|
80 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.21 mm
|
|
OSRAM OSLON™ SSL 150, GR CSHPM1.23
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.74 W
|
High
|
68 lm
|
13.2 cd
|
369 mW
|
71.6 mW/sr
|
150 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.51 mm
|
|
OSRAM OSLON™ Optimal, GR CSSRML.24
|
A brand new family of LEDs with our ams OSRAM’s latest chip technology, delivering significant performance upgrades. The OSLON™ Optimal strikes a perfect balance of performance and cost along with proven robustness, high reliability and long lifetime.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.73 W
|
High
|
70 lm
|
22.3 cd
|
490 mW
|
156 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.12 mm
|
|
OSRAM OSCONIQ™ P 2226, GR DASPA2.23
|
High-efficacy mid-power LED with long lifetimes also at high currents and high junction temperatures.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.21 W
|
Mid
|
21 lm
|
6.37 cd
|
99.1 mW
|
30.1 mW/sr
|
120 °
|
-40 °C
|
120 °C
|
2.6 mm
|
2.2 mm
|
1.25 mm
|
|
OSRAM DURIS™ E 2835, GR JTLPS1.23
|
The DURIS™ E 2835 color family provide excellent color rendering and supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.32 W
|
Mid
|
27.8 lm
|
8.96 cd
|
127 mW
|
40.9 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM DURIS™ S 5, GR PSLM31.23
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.21 W
|
Mid
|
18.5 lm
|
6.05 cd
|
87.3 mW
|
28.5 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM DURIS™ S 5, GR PSLR31.13
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.94 W
|
High
|
28.5 lm
|
9.82 cd
|
278 mW
|
95.8 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM OSCONIQ™ P 3030, GR QSSPA1.23
|
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.76 W
|
High
|
90.3 lm
|
27.1 cd
|
440 mW
|
132 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.63 mm
|
0.473 µmol/s
|
|
OSRAM OSLON™ Pure 1414, GR VJLPL1.23
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.79 W
|
High
|
85 lm
|
21.1 cd
|
543 mW
|
135 mW/sr
|
140 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.85 mm
|
|
OSRAM OSLON™ Pure 1414, GR VJLPL1.F3
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
1.0 W
|
High
|
40 lm
|
13.3 cd
|
253 mW
|
83.9 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.85 mm
|
|
OSRAM OSLON™ SSL 80, GT CS8PM1.13
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.95 W
|
High
|
122 lm
|
72.4 cd
|
238 mW
|
141 mW/sr
|
80 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.21 mm
|
|
OSRAM OSLON™ SSL 150, GT CSHPM1.13
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.95 W
|
High
|
130 lm
|
30.9 cd
|
254 mW
|
60.3 mW/sr
|
150 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.51 mm
|
|
OSRAM OSLON™ SSL 120, GT CSSPM1.13
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.93 W
|
High
|
130 lm
|
41.4 cd
|
254 mW
|
80.7 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.75 mm
|
|
OSRAM OSCONIQ™ P 2226, GT DASPA2.13
|
High-efficacy mid-power LED with long lifetimes also at high currents and high junction temperatures.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.28 W
|
Mid
|
30.8 lm
|
9.48 cd
|
59.9 mW
|
18.4 mW/sr
|
110 °
|
-40 °C
|
120 °C
|
2.6 mm
|
2.2 mm
|
1.25 mm
|
|
OSRAM DURIS™ E 2835, GT JTLPS1.13
|
The DURIS™ E 2835 color family provide excellent supreme efficacy in cost effective industry standard LED. DURIS™ E 2835 never fails to impress with its performance on system level.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.44 W
|
Mid
|
80 lm
|
25.8 cd
|
166 mW
|
53.4 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.5 mm
|
2.8 mm
|
0.7 mm
|
|
OSRAM DURIS™ S 5, GT PSLM31.13
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.27 W
|
Mid
|
37.5 lm
|
12.3 cd
|
72.9 mW
|
24 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM DURIS™ S 5, GT PSLR31.13
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.94 W
|
High
|
187 lm
|
64.4 cd
|
386 mW
|
133 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM OSCONIQ™ P 3030, GT QSSPA1.13
|
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.95 W
|
High
|
160 lm
|
51 cd
|
312 mW
|
99.5 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM OSLON™ Pure 1414, GT VJLPL1.13
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.93 W
|
High
|
121 lm
|
41.3 cd
|
252 mW
|
86 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.75 mm
|
|
OSRAM OSCONIQ™ P 3030, GV QSSPA1.13
|
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
|
LEDs
|
Color LEDs
|
Verde (495-512 nm)
|
1.0 W
|
High
|
86.5 lm
|
24.1 cd
|
572 mW
|
160 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM OSLON™ Pure 1414, GV VJLPL1.F3
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Verde (495-512 nm)
|
1.0 W
|
High
|
132 lm
|
43.9 cd
|
497 mW
|
165 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.75 mm
|
|
OSRAM OSCONIQ™ P 3737 (2W), GW PUSRA1.HW
|
High-power LED with our ams OSRAM’s latest chip technology, delivering industry leading performance, superior robustness and long lifetime. With the introduction of a new color
(Red 640 nm) the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
The OSCONIQ™ P 3737 family offers Hyper Red (660 nm), Red (640nm), Deep Blue (450 nm), Far Red (730 nm) and Horti White which can cater to both narrow spectrum and full
spectrum solutions to meet all crop needs for both greenhouses and vertical farms.
|
LEDs
|
Color LEDs
|
White
|
2.0 W
|
High
|
390 lm
|
128 cd
|
1160 mW
|
379 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.15 mm
|
5.1 µmol/s
|
|
OSRAM OSLON™ Pure 1414, GW VJLPL1.UL
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
1.0 W
|
High
|
198 lm
|
66.1 cd
|
439 mW
|
147 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.75 mm
|
0.944 µmol/s
|
|
OSRAM OSLON™ Pure 1414, GW VJLPL1.WB
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
1.0 W
|
High
|
179 lm
|
59.8 cd
|
397 mW
|
133 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.75 mm
|
|
OSRAM OSLON™ SSL 80, GY CS8PM1.23
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.77 W
|
High
|
76 lm
|
45.7 cd
|
154 mW
|
92.5 mW/sr
|
80 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.21 mm
|
|
OSRAM OSLON™ SSL 150, GY CSHPM1.23
|
New, higher performing OSLON SSL family LED with well known superior robustness, high reliability, long lifetime, low thermal resistance. Perfectly addressing applications demanding for high efficiency and long lifetime requirement.
|
LEDs
|
Color LEDs
|
0.77 W
|
High
|
76 lm
|
15.7 cd
|
154 mW
|
31.7 mW/sr
|
150 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
1.59 mm
|
|
OSRAM OSCONIQ™ P 2226, GY DASPA2.23
|
High-efficacy mid-power LED with long lifetimes also at high currents and high junction temperatures.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.22 W
|
Mid
|
16 lm
|
5 cd
|
31.9 mW
|
9.97 mW/sr
|
120 °
|
-40 °C
|
120 °C
|
2.6 mm
|
2.2 mm
|
1.25 mm
|
|
OSRAM DURIS™ S 5, GY PSLM31.13
|
The compact, mid-power Duris™ S 5 LED with industry standard 3030 package that comes with high efficacy, color quality and long lifetime. Ideal choice for indoor General Lighting applications.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.3 W
|
Mid
|
34.5 lm
|
11.7 cd
|
122 mW
|
41.2 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.6 mm
|
|
OSRAM OSCONIQ™ P 3030, GY QSSPA1.13
|
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
1.0 W
|
High
|
101 lm
|
30.8 cd
|
354 mW
|
108 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM OSLON™ Pure 1414, GY VJLPL1.F3
|
The OSLON Pure™ 1414, one of the best lumen density, excellent efficiency and color homogeneity.
The OSLON Pure™ 1414 come with full color spectrum and color temperature of 1800K to 6500K that enable customer to perform color tuning and tight clustering. It can be use stand alone as well as in cluster together to achieve the spectrum that you need.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
1.0 W
|
High
|
116 lm
|
39.1 cd
|
311 mW
|
105 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
1.4 mm
|
1.4 mm
|
0.85 mm
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KB CSLNM1.14
|
High luminance device in a reliable ceramic package configuration dedicated for RGB projection systems in automotive enviroments
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
3.0 W
|
High
|
34.5 lm
|
11.6 cd
|
1350 mW
|
452 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KB CULPM1.14
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
4.1 W
|
High
|
47.8 lm
|
16 cd
|
1870 mW
|
626 mW/sr
|
110 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM SYNIOS™ S2222, KB DDLM32.13
|
The square package with just 2mm outline combines best performance with a small footprint for environments where improved corrosion robustness is needed. A centralized chip allows an easy integration into optical systems. The availability of all main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.28 W
|
Mid
|
9.25 lm
|
3.08 cd
|
125 mW
|
41.6 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.2 mm
|
2.2 mm
|
0.65 mm
|
|
OSRAM TOPLED™ E1608, KB DELPS2.12
|
The TOPLED E1608 expands ams-OSRAM's low power portfolio to meet the requirements in the field of illumination of switches and buttons in automotive interior applications. The TOPLED E1608 offers one of the smallest LED industry standard footprints in a highly reliable and well proved package concept. The TOPLED E1608 is available in different colors and brightness levels. Its outstanding performance is suitable for a huge variety of applications where a small package design with excellent reliability is needed.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.028 W
|
Low
|
0.443 lm
|
0.131 cd
|
7.91 mW
|
2.34 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KB DELPS2.D2
|
The TOPLED E1608 expands ams-OSRAM's low power portfolio to meet the requirements in the field of illumination of switches and buttons in automotive interior applications. The TOPLED E1608 offers one of the smallest LED industry standard footprints in a highly reliable and well proved package concept. The TOPLED E1608 is available in different colors and brightness levels. Its outstanding performance is suitable for a huge variety of applications where a small package design with excellent reliability is needed.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.014 W
|
Low
|
0.624 lm
|
0.205 cd
|
4.87 mW
|
1.6 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KB DELPS2.DI
|
The TOPLED E1608 expands ams OSRAM’ low power portfolio by offering one of the smallest LED Industry standard footprints in a highly reliable and well proved package concept.
Its outstanding performance is suitable for a huge variety of applications especially automotive interior where a small package design with excellent reliability is needed. The TOPLED E1608 is available in different colors and brightness levels.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.029 W
|
Low
|
1.73 lm
|
0.575 cd
|
6.53 mW
|
2.17 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KB DELSS2.12
|
The TOPLED E1608 expands ams OSRAM's low power portfolio to meet the requirements in the field of illumination of switches and buttons in automotive interior applications. It offers one of the smallest LED industry standard footprints in a highly reliable and well proved package concept. The TOPLED E1608 is available in different colors and brightness levels. Its outstanding performance is suitable for a huge variety of applications where a small package design with excellent reliability is needed.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.062 W
|
Low
|
1.38 lm
|
0.47 cd
|
21.3 mW
|
7.28 mW/sr
|
115 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KB DELSS2.D1
|
The TOPLED E1608 expands ams OSRAM’ low power portfolio by offering one of the smallest LED Industry standard footprints in a highly reliable and well proved package concept.
Its outstanding performance is suitable for a huge variety of applications especially automotive interior where a small package design with excellent reliability is needed. The TOPLED E1608 is available in different colors and brightness levels.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.062 W
|
Low
|
3.99 lm
|
1.31 cd
|
19.3 mW
|
6.33 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KB DELSS2.D2
|
The TOPLED E1608 expands ams OSRAM’ low power portfolio by offering one of the smallest LED Industry standard footprints in a highly reliable and well proved package concept.
Its outstanding performance is suitable for a huge variety of applications especially automotive interior where a small package design with excellent reliability is needed. The TOPLED E1608 is available in different colors and brightness levels.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.062 W
|
Low
|
3.36 lm
|
1.11 cd
|
19.4 mW
|
6.36 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KB DMLN31.13
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KB DMLN31.13 product is meant to provide superior light quality in ¼ mm² chip size class.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.6 W
|
Mid
|
11.8 lm
|
3.93 cd
|
340 mW
|
113 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KB DMLQ31.13
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint. The KB DMLQ31.13 product is meant to provide superior light quality in ½ mm² chip size class.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
1.0 W
|
High
|
22.8 lm
|
7.58 cd
|
656 mW
|
219 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, KB EELP41.12
|
The SMARTLED™ 0603 is the product of choice for status indication and symbol backlighting in electronics.
The small package size allows compact designs. The improved corrosion robustness and increased junction temperature range makes the devices from this series suitable for professional industrial equipment and applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.014 W
|
Low
|
0.358 lm
|
0.0915 cd
|
4.19 mW
|
1.07 mW/sr
|
130 °
|
145 °
|
-40 °C
|
105 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM SYNIOS™ P2222, KC DDLN31.13
|
The SYNIOS™ P2222 is the new standard mid-power LED for Automotive Signaling applications. It features a small package outline and is available in all application-specific colors.
|
LEDs
|
Color LEDs
|
Cyan (482-492 nm)
|
0.65 W
|
Mid
|
16.8 lm
|
5.72 cd
|
83.9 mW
|
28.6 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
0.0694 µmol/s
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, KG EELP41.22
|
The SMARTLED™ 0603 is the product of choice for status indication and symbol backlighting in electronics.
The small package size allows compact designs. The improved corrosion robustness and increased junction temperature range makes the devices from this series suitable for professional industrial equipment and applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.042 W
|
Low
|
0.251 lm
|
0.0715 cd
|
0.399 mW
|
0.114 mW/sr
|
130 °
|
130 °
|
-40 °C
|
105 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM TOPLED™ E1608, KO DELPS1.22
|
The TOPLED E1608 expands ams OSRAM's low power portfolio to meet the requirements in the field of illumination of switches and buttons in automotive interior applications. It offers one of the smallest LED industry standard footprints in a highly reliable and well proved package concept. The TOPLED E1608 is available in different colors and brightness levels. Its outstanding performance is suitable for a huge variety of applications where a small package design with excellent reliability is needed.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.043 W
|
Low
|
2.59 lm
|
0.785 cd
|
7.05 mW
|
2.14 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, KO EELP41.22
|
The SMARTLED™ 0603 is the product of choice for status indication and symbol backlighting in electronics.
The small package size allows compact designs. The improved corrosion robustness and increased junction temperature range makes the devices from this series suitable for professional industrial equipment and applications.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.666 lm
|
0.182 cd
|
1.81 mW
|
0.495 mW/sr
|
130 °
|
130 °
|
-40 °C
|
105 °C
|
1.6 mm
|
0.8 mm
|
0.8 mm
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KP CSLMM1.F1
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
2.3 W
|
High
|
365 lm
|
117 cd
|
809 mW
|
260 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
1.65 µmol/s
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KP CSLMMA.F1
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
2.3 W
|
High
|
365 lm
|
117 cd
|
809 mW
|
260 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
1.65 µmol/s
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KP CSLNM1.F1
|
High luminance device in a reliable ceramic package configuration dedicated for RGB projection systems in automotive environments.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
3.0 W
|
High
|
515 lm
|
173 cd
|
1130 mW
|
379 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KP CSLPM1.F1
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
4.2 W
|
High
|
680 lm
|
228 cd
|
1490 mW
|
500 mW/sr
|
120 °
|
-40 °C
|
85 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM TOPLED™ E1608, KP DELPS1.FP
|
The TOPLED E1608 expands ams OSRAM’ low power portfolio by offering one of the smallest LED Industry standard footprints in a highly reliable and well proved package concept.
Its outstanding performance is suitable for a huge variety of applications especially automotive interior where a small package design with excellent reliability is needed. The TOPLED E1608 is available in different colors and brightness levels.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
0.029 W
|
Low
|
2.36 lm
|
0.785 cd
|
4.62 mW
|
1.54 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KR CSLNM1.23
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
2.4 W
|
High
|
146 lm
|
47.2 cd
|
566 mW
|
183 mW/sr
|
120 °
|
-40 °C
|
105 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KR CULPM1.23
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
3.0 W
|
High
|
187 lm
|
69.9 cd
|
1050 mW
|
391 mW/sr
|
110 °
|
-40 °C
|
100 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM SYNIOS™ S2222, KR DDLM32.23
|
The square package with just 2mm outline combines best performance with a small footprint for environments where improved corrosion robustness is needed. A centralized chip allows an easy integration into optical systems. The availability of all main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.22 W
|
Mid
|
28.3 lm
|
9.27 cd
|
135 mW
|
44.2 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.2 mm
|
2.2 mm
|
0.65 mm
|
|
OSRAM SYNIOS™ P2222, KR DDLN31.23
|
The SYNIOS™ P2222 is the new standard mid-power LED for Automotive Signaling applications. It features a small package outline and is available in all application-specific colors.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.47 W
|
Mid
|
40.5 lm
|
13.5 cd
|
230 mW
|
76.8 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
0.214 µmol/s
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KR DELPS1.22
|
The TOPLED E1608 expands ams OSRAM’ low power portfolio by offering one of the smallest LED Industry standard footprints in a highly reliable and well proved package concept.
Its outstanding performance is suitable for a huge variety of applications especially automotive interior where a small package design with excellent reliability is needed. The TOPLED E1608 is available in different colors and brightness levels.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.043 W
|
Low
|
2.68 lm
|
0.82 cd
|
10.5 mW
|
3.21 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KR DMLN31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KR DMLN31.23 product is meant to provide superior light quality in ¼ mm² chip size class.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.46 W
|
Mid
|
41 lm
|
13.2 cd
|
167 mW
|
53.7 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KR DMLQ31.FR
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KR DMLQ31.FR product is meant to provide superior light quality in ½ mm² chip size class.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
1.0 W
|
High
|
50.9 lm
|
17.6 cd
|
263 mW
|
91 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KR DMLQ32.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint. The KR DMLQ32.23 product is meant to provide superior light quality in ½ mm² chip size class.The next generation SYNIOS™ P2720
Kx DMLQ32.23 delivers higher performance, while remaining fully footprint- and solder pad-compatible to the previous version.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
1.8 W
|
High
|
87.5 lm
|
28.1 cd
|
475 mW
|
153 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.0 mm
|
2.7 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KR DMLS31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KR DMLS31.23 product is meant to provide superior light quality in 1 mm² chip size class.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
1.8 W
|
High
|
126 lm
|
40.4 cd
|
715 mW
|
230 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KR DMLS31.FR
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KR DMLS31.FR product is meant to provide superior light quality in 1 mm² chip size class.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
2.1 W
|
High
|
108 lm
|
37.2 cd
|
556 mW
|
192 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, KR EELP41.22
|
The SMARTLED™ 0603 is the product of choice for status indication and symbol backlighting in electronics.
The small package size allows compact designs. The improved corrosion robustness and increased junction temperature range makes the devices from this series suitable for professional industrial equipment and applications.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.039 W
|
Low
|
0.408 lm
|
0.115 cd
|
2.3 mW
|
0.648 mW/sr
|
130 °
|
130 °
|
-40 °C
|
105 °C
|
1.6 mm
|
0.8 mm
|
0.7 mm
|
|
OSRAM Chip LED 0402, KR EGLP41.22
|
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.039 W
|
Low
|
0.298 lm
|
0.113 cd
|
1.53 mW
|
0.578 mW/sr
|
75 °
|
140 °
|
-40 °C
|
85 °C
|
1.0 mm
|
0.5 mm
|
0.25 mm
|
|
OSRAM SYNIOS™ P1515, KR SITQA1.23
|
The SYNIOS™ P1515 expands ams OSRAM’ low power portfolio by offering a small LED Industry standard footprint. The unique 360° radiation characteristic makes it fit perfect for a huge variety of applications especially in automotive exterior. Where either a small optical distance to the cover glass or homogeneous area illumination is required, the SYNIOS™ P1515 shows significant benefits. These unique features give freedom to very thin and flexible designed RCL-Modules.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.11 W
|
Low
|
9.8 lm
|
0.138 cd
|
40.7 mW
|
0.574 mW/sr
|
-40 °C
|
110 °C
|
1.5 mm
|
1.5 mm
|
1.42 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ S2222, KS DDLM32.23
|
The square package with just 2mm outline combines best performance with a small footprint for environments where improved corrosion robustness is needed. A centralized chip allows an easy integration into optical systems. The availability of all main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.22 W
|
Mid
|
16.5 lm
|
5.38 cd
|
115 mW
|
37.5 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.2 mm
|
2.2 mm
|
0.6 mm
|
|
OSRAM SYNIOS™ P2222, KS DDLN31.23
|
The SYNIOS™ P2222 is the new standard mid-power LED for Automotive Signaling applications. It features a small package outline and is available in all application-specific colors.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.45 W
|
Mid
|
29 lm
|
9.68 cd
|
245 mW
|
81.9 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
0.156 µmol/s
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KS DELPS1.22
|
The TOPLED E1608 expands ams OSRAM's low power portfolio to meet the requirements in the field of illumination of switches and buttons in automotive interior applications. It offers one of the smallest LED industry standard footprints in a highly reliable and well proved package concept. The TOPLED E1608 is available in different colors and brightness levels. Its outstanding performance is suitable for a huge variety of applications where a small package design with excellent reliability is needed.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.043 W
|
Low
|
2.24 lm
|
0.68 cd
|
17 mW
|
5.16 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KS DMLN31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KS DMLN31.23 product is meant to provide superior light quality in ¼ mm² chip size class.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.46 W
|
Mid
|
27 lm
|
8.68 cd
|
228 mW
|
73.5 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KS DMLQ32.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint. The KS DMLQ32.23 product is meant to provide superior light quality in ½ mm² chip size class. The next generation SYNIOS™ P2720
Kx DMLQ32.23 delivers higher performance, while remaining fully footprint- and solder pad-compatible to the previous version.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
1.8 W
|
High
|
51.3 lm
|
16.5 cd
|
430 mW
|
138 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.0 mm
|
2.7 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KS DMLS31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KS DMLS31.23 product is meant to provide superior light quality in 1 mm² chip size class.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
1.7 W
|
High
|
81 lm
|
26.1 cd
|
600 mW
|
193 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, KS EELP41.22
|
The SMARTLED™ 0603 is the product of choice for status indication and symbol backlighting in electronics.
The small package size allows compact designs. The improved corrosion robustness and increased junction temperature range makes the devices from this series suitable for professional industrial equipment and applications.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.039 W
|
Low
|
0.291 lm
|
0.084 cd
|
2.01 mW
|
0.581 mW/sr
|
130 °
|
130 °
|
-40 °C
|
105 °C
|
1.6 mm
|
0.8 mm
|
0.8 mm
|
|
OSRAM SYNIOS™ P1515, KS SITQA1.23
|
The SYNIOS™ P1515 expands ams OSRAM’ low power portfolio by offering a small LED Industry standard footprint. The unique 360° radiation characteristic makes it fit perfect for a huge variety of applications especially in automotive exterior. Where either a small optical distance to the cover glass or homogeneous area illumination is required, the SYNIOS™ P1515 shows significant benefits. These unique features give freedom to very thin and flexible designed RCL-Modules.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.11 W
|
Low
|
6.5 lm
|
0.0943 cd
|
51.2 mW
|
0.742 mW/sr
|
-40 °C
|
110 °C
|
1.5 mm
|
1.5 mm
|
1.42 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KT CSLNM1.13
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
2.9 W
|
High
|
230 lm
|
77 cd
|
527 mW
|
176 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KT CULPM1.13
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
3.9 W
|
High
|
377 lm
|
134 cd
|
774 mW
|
275 mW/sr
|
110 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM SYNIOS™ S2222, KT DDLM32.13
|
The square package with just 2mm outline combines best performance with a small footprint for environments where improved corrosion robustness is needed. A centralized chip allows an easy integration into optical systems. The availability of all main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.28 W
|
Mid
|
45.1 lm
|
15.6 cd
|
92.2 mW
|
31.8 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.2 mm
|
2.2 mm
|
0.65 mm
|
|
OSRAM TOPLED™ E1608, KT DELQS1.12
|
The TOPLED E1608 expands ams OSRAM’ low power portfolio by offering one of the smallest LED Industry standard footprints in a highly reliable and well proved package concept.
Its outstanding performance is suitable for a huge variety of applications especially automotive interior where a small package design with excellent reliability is needed. The TOPLED E1608 is available in different colors and brightness levels.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.027 W
|
Low
|
2.16 lm
|
0.68 cd
|
4.4 mW
|
1.39 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KT DELSS1.12
|
The TOPLED E1608 expands ams OSRAM’ low power portfolio by offering one of the smallest LED Industry standard footprints in a highly reliable and well proved package concept.
Its outstanding performance is suitable for a huge variety of applications especially automotive interior where a small package design with excellent reliability is needed. The TOPLED E1608 is available in different colors and brightness levels.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.052 W
|
Low
|
6.32 lm
|
2.05 cd
|
12.3 mW
|
4 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KT DMLN31.13
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint. The KT DMLN31.13 product is meant to provide superior light quality in ¼ mm² chip size class. The higher robustness and standardized footprint makes the LED flexible for any RGBW application.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.17 W
|
Mid
|
25 lm
|
8.33 cd
|
48.6 mW
|
16.2 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, KT EELP41.12
|
The SMARTLED™ 0603 is the product of choice for status indication and symbol backlighting in electronics.
The small package size allows compact designs. The improved corrosion robustness and increased junction temperature range makes the devices from this series suitable for professional industrial equipment and applications.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.013 W
|
Low
|
1.44 lm
|
0.365 cd
|
2.78 mW
|
0.704 mW/sr
|
130 °
|
145 °
|
-40 °C
|
105 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM OSLON™ Compact PL, KY CELNM2.FY
|
Compact light source with an isolated thermal pad for improved heat dissipation and providing small z-tolerance (+/-35 µm).
The OSLON Compact PL product family meets both excellent brightness in combination with outstanding luminance.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
3.1 W
|
High
|
280 lm
|
94 cd
|
789 mW
|
265 mW/sr
|
120 °
|
-40 °C
|
135 °C
|
1.9 mm
|
1.5 mm
|
0.74 mm
|
1.43 µmol/s
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, KY CSLNM1.FY
|
Compact light source with isolated heat sink for improved heat dissipation and high current chip technology for increased light output.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
3.0 W
|
High
|
210 lm
|
69.8 cd
|
597 mW
|
198 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
0.75 mm
|
|
OSRAM OSLON™ Compact PL, KY CWLNM2.FY
|
Compact light source with improved heat dissipation and small z-tolerance (+/- 35 µm). This special device in the OSLON Compact PL family combines the advantages of a ceramic package with outstanding efficiency.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
3.1 W
|
High
|
280 lm
|
94 cd
|
789 mW
|
265 mW/sr
|
120 °
|
-40 °C
|
135 °C
|
1.9 mm
|
1.5 mm
|
0.74 mm
|
1.43 µmol/s
|
AEC-Q102
|
|
OSRAM SYNIOS™ S2222, KY DDLM32.23
|
The square package with just 2mm outline combines best performance with a small footprint for environments where improved corrosion robustness is needed. A centralized chip allows an easy integration into optical systems. The availability of all main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.22 W
|
Mid
|
26 lm
|
8.7 cd
|
49.1 mW
|
16.2 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.2 mm
|
2.2 mm
|
0.65 mm
|
|
OSRAM SYNIOS™ S2222, KY DDLM32.FY
|
The square package with just 2mm outline combines best performance with a small footprint for environments where improved corrosion robustness is needed. A centralized chip allows an easy integration into optical systems. The availability of all main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.29 W
|
Mid
|
35 lm
|
11.9 cd
|
110 mW
|
37.3 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.2 mm
|
2.2 mm
|
0.65 mm
|
0.18 µmol/s
|
|
OSRAM SYNIOS™ P2222, KY DDLN31.23
|
The SYNIOS™ P2222 is the new standard mid-power LED for Automotive Signaling applications. It features a small package outline and is available in all application-specific colors.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.47 W
|
Mid
|
31.5 lm
|
10.5 cd
|
59.7 mW
|
19.9 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
0.155 µmol/s
|
AEC-Q102
|
|
OSRAM TOPLED™ E1608, KY DELPS1.22
|
The TOPLED E1608 expands ams-OSRAM's low power portfolio to meet the requirements in the field of illumination of switches and buttons in automotive interior applications. The TOPLED E1608 offers one of the smallest LED industry standard footprints in a highly reliable and well proved package concept. The TOPLED E1608 is available in different colors and brightness levels. Its outstanding performance is suitable for a huge variety of applications where a small package design with excellent reliability is needed.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.044 W
|
Low
|
2.59 lm
|
0.785 cd
|
5.19 mW
|
1.58 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KY DMLN31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KY DMLN31.23 product is meant to provide superior light quality in ¼ mm² chip size class.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.47 W
|
Mid
|
35 lm
|
11.3 cd
|
70 mW
|
22.5 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KY DMLN31.FY
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KY DMLN31.FY product is meant to provide superior light quality in ¼ mm² chip size class.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.44 W
|
Mid
|
31.2 lm
|
10.8 cd
|
110 mW
|
38 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KY DMLQ31.FY
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KY DMLQ31.FY product is meant to provide superior light quality in ½ mm² chip size class.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.89 W
|
High
|
88.7 lm
|
30.7 cd
|
271 mW
|
93.8 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KY DMLQ32.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint. The KY DMLQ32.23 product is meant to provide superior light quality in ½ mm² chip size class. The next generation SYNIOS™ P2720
Kx DMLQ32.23 delivers higher performance, while remaining fully footprint- and solder pad-compatible to the previous version.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
1.8 W
|
High
|
67.8 lm
|
21.8 cd
|
135 mW
|
43.6 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.0 mm
|
2.7 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KY DMLS31.FY
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KY DMLS31.FY product is meant to provide superior light quality in 1 mm² chip size class.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
1.8 W
|
High
|
143 lm
|
49.4 cd
|
504 mW
|
174 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, KY EELP41.22
|
The SMARTLED™ 0603 is the product of choice for status indication and symbol backlighting in electronics.
The small package size allows compact designs. The improved corrosion robustness and increased junction temperature range makes the devices from this series suitable for professional industrial equipment and applications.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
0.658 lm
|
0.182 cd
|
1.29 mW
|
0.357 mW/sr
|
130 °
|
130 °
|
-40 °C
|
105 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM SYNIOS™ P1515, KY SITQA1.23
|
The SYNIOS™ P1515 expands ams OSRAM’ low power portfolio by offering a small LED Industry standard footprint. The unique 360° radiation characteristic makes it fit perfect for a huge variety of applications especially in automotive exterior. Where either a small optical distance to the cover glass or homogeneous area illumination is required, the SYNIOS™ P1515 shows significant benefits. These unique features give freedom to very thin and flexible designed RCL-Modules.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
7.5 lm
|
0.114 cd
|
15 mW
|
0.227 mW/sr
|
-40 °C
|
110 °C
|
1.5 mm
|
1.5 mm
|
1.42 mm
|
AEC-Q102
|
|
OSRAM SIDELED™, LA A67F
|
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.06 W
|
Low
|
7.15 lm
|
2.33 cd
|
28.9 mW
|
9.44 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
4.0 mm
|
4.0 mm
|
3.6 mm
|
|
OSRAM Power SIDELED™, LA B6SP
|
Power SIDELED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.31 W
|
Mid
|
35.2 lm
|
11.8 cd
|
143 mW
|
48 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
4.8 mm
|
4.8 mm
|
3.8 mm
|
AEC-Q102
|
|
OSRAM OSLON™ SX, LA CN5M
|
The OSLON™ SX combine a compact size (small footprint: 3x3mm) with a high efficiency and a electrically insulated thermal pad.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.3 W
|
Mid
|
26.8 lm
|
19.8 cd
|
109 mW
|
80.7 mW/sr
|
60 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.43 mm
|
|
OSRAM Power TOPLED™ Lens, LA E63F
|
PowerTOPLED with lens, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
9.87 lm
|
34.2 cd
|
39.2 mW
|
136 mW/sr
|
30 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.8 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™ Lens, LA E65F
|
PowerTOPLED with lens, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
10.2 lm
|
9.25 cd
|
40.6 mW
|
36.8 mW/sr
|
60 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.5 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™ Lens, LA E65FP
|
PowerTOPLED with lens, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
9.8 lm
|
8.87 cd
|
39 mW
|
35.3 mW/sr
|
60 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
3.5 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LA E67F
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
9.75 lm
|
3.2 cd
|
38.7 mW
|
12.7 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0166 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LA E67F.01
|
PowerTOPLED, a powerful member of the TOPLED
family. Thanks to their high luminous efficacy, the
LEDs are ideal for rear light clusters and indicators
on vehicles and for display panels for traffic control
systems.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
10.3 lm
|
3.35 cd
|
42.6 mW
|
13.9 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0175 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LA E6SF
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
8.8 lm
|
2.9 cd
|
35 mW
|
11.5 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.015 µmol/s
|
|
OSRAM Power TOPLED™, LA ETSF
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.11 W
|
Low
|
10.3 lm
|
3.37 cd
|
40.8 mW
|
13.4 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Advanced Power TOPLED™, LA G6SP.01
|
Latest version of Advanced Power TOPLED with increased brightness and improved thermal management.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.31 W
|
Mid
|
28.3 lm
|
9.5 cd
|
115 mW
|
38.7 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Advanced Power TOPLED™, LA G6SP.02
|
The Advanced Power TOPLED.02 (APT.02) features ams OSRAM’s state-of-the-art generation of PLCC 6 packages, which have set a market standard in the mid power LED world and were decades ago the first of its kind. With its very robust design, the APT.02 family can withstand harsh environmental conditions and offers the highest level of processability. Containing our latest InGaAlP-chip technology the APT.02 keeps its market leading brightness performance and offers a wide range of available bins with a high luminous efficiency and an excellent thermal resistance.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.32 W
|
Mid
|
34.3 lm
|
11.5 cd
|
140 mW
|
46.8 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
0.0598 µmol/s
|
AEC-Q102
|
|
OSRAM OSLON™ Black, LA H9GP
|
OSLON Black Series combines thermal stability with high performance and reliability in a compact black package. It has a metal lead frame and a tried and tested lens design. The LED can be used wherever there are large fluctuations in temperature and a large amount of light is needed from a small area.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.77 W
|
High
|
82 lm
|
37.7 cd
|
334 mW
|
154 mW/sr
|
90 °
|
-40 °C
|
125 °C
|
3.75 mm
|
3.75 mm
|
2.29 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Black Flat, LA H9PP
|
OSLON Black Flat is a new small size high-flux LED for slim designs. The black package stands for high stability.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.77 W
|
High
|
63.5 lm
|
21.1 cd
|
259 mW
|
86 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.75 mm
|
3.75 mm
|
0.5 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LA M676
|
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.04 W
|
Low
|
0.678 lm
|
0.223 cd
|
2.76 mW
|
0.905 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LA M67F.01
|
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.043 W
|
Low
|
3.91 lm
|
1.26 cd
|
15.8 mW
|
5.06 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LA P47F
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.062 W
|
Low
|
5.67 lm
|
1.85 cd
|
22.5 mW
|
7.35 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LA T676
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.04 W
|
Low
|
0.678 lm
|
0.223 cd
|
2.76 mW
|
0.905 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LA T67F.01
|
SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality and extreme robust product for all kind of applications. With the latest generation (.01) we will continue this successful path.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.043 W
|
Low
|
6.1 lm
|
1.96 cd
|
24.6 mW
|
7.91 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Signal, LB CRBP.01
|
The OSLON™ Signal combines a compact form factor with high efficiency and electrically insulated thermal pad. The square package matches the optical center with the mechanical center. This provides easy clustering flexibility and high packing density for a maximum flux density.
The color bins are defined for best fit to most signaling norms.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
1.0 W
|
High
|
50 lm
|
15.3 cd
|
1890 mW
|
578 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.12 mm
|
0.187 µmol/s
|
|
OSRAM Power TOPLED™, LB E6SG
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.093 W
|
Low
|
1.92 lm
|
0.628 cd
|
27.9 mW
|
9.12 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM Advanced Power TOPLED™, LB G6SP
|
Advanced Power TOPLED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.46 W
|
Mid
|
9.38 lm
|
3.15 cd
|
276 mW
|
92.5 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LB M67D
|
Small size high-flux LED for slim designs
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.0039 W
|
Low
|
0.117 lm
|
0.037 cd
|
1.69 mW
|
0.537 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LB P4SG
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.06 W
|
Low
|
1.19 lm
|
0.392 cd
|
17.4 mW
|
5.7 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
|
OSRAM Chip LED 0603, LB Q99G.01
|
The Chip LED 0603 is the product of choice for low power status indication in electronics. The small package size allows compact designs, like 7-segment displays, symbol backlighting or button and switch illumination in control panels. The high brightness of the LED ensures good visibility at any time.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.014 W
|
Low
|
0.428 lm
|
0.0925 cd
|
6.05 mW
|
1.31 mW/sr
|
140 °
|
-40 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.7 mm
|
|
OSRAM Chip LED 0402, LB QH9G
|
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.014 W
|
Low
|
0.414 lm
|
0.104 cd
|
5.55 mW
|
1.39 mW/sr
|
115 °
|
170 °
|
-40 °C
|
85 °C
|
1.0 mm
|
0.5 mm
|
0.35 mm
|
|
OSRAM TOPLED™ Black, LB T64G
|
TOPLED Black is especially designed for variable message signs (VMS) and price changers. The black package offers premium contrast for display panels.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.057 W
|
Low
|
0.908 lm
|
1.82 cd
|
16.1 mW
|
32.3 mW/sr
|
30 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.65 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LB TTSD
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.06 W
|
Low
|
0.959 lm
|
0.315 cd
|
12.9 mW
|
4.22 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Micro SIDELED™ 2808, LB Y1SG
|
Micro SIDELED is a SMT LED with side emission. Due to its low package height it is ideal for applications in limited space environments.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.057 W
|
Low
|
1.7 lm
|
0.495 cd
|
21.5 mW
|
6.24 mW/sr
|
120 °
|
-40 °C
|
85 °C
|
2.8 mm
|
1.2 mm
|
0.8 mm
|
|
OSRAM SIDELED™, LCB A6SG
|
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.06 W
|
Low
|
3.96 lm
|
1.26 cd
|
15.7 mW
|
4.98 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
4.0 mm
|
4.0 mm
|
3.6 mm
|
|
OSRAM OSLON™ Signal, LCB CRBP.01
|
The OSLON™ Signal combines a compact form factor with high efficiency and electrically insulated thermal pad. The square package matches the optical center with the mechanical center. This provides easy clustering flexibility and high packing density for a maximum flux density.
The color bins are defined for best fit to most signaling norms.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
1.0 W
|
High
|
101 lm
|
30.3 cd
|
712 mW
|
214 mW/sr
|
125 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.17 mm
|
|
OSRAM Power TOPLED™, LCB E6SG
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.093 W
|
Low
|
5.69 lm
|
1.96 cd
|
22.6 mW
|
7.77 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM Advanced Power TOPLED™, LCB G6SP
|
Advanced Power TOPLED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.46 W
|
Mid
|
29.2 lm
|
9.8 cd
|
118 mW
|
39.7 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LCB M67D
|
Small size high-flux LED for slim designs
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.014 W
|
Low
|
1.17 lm
|
0.37 cd
|
4.62 mW
|
1.47 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LCB P4SD
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.0055 W
|
Low
|
0.359 lm
|
0.118 cd
|
1.23 mW
|
0.403 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
|
OSRAM TOPLED™, LCB TTSD
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.029 W
|
Low
|
0.309 lm
|
0.098 cd
|
1.25 mW
|
0.395 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LCB TVSG
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.061 W
|
Low
|
5.78 lm
|
1.96 cd
|
22.2 mW
|
7.54 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.83 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Compact CL, LCY CEUP
|
Compact light source with a typical luminous flux of 125 lm at 700 mA and an operation range of 50 mA up to 1000 mA
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
2.2 W
|
High
|
175 lm
|
58 cd
|
503 mW
|
167 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
1.9 mm
|
1.5 mm
|
0.752 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Signal, LCY CRBP.01
|
The OSLON™ Signal combines a compact form factor with high efficiency and electrically insulated thermal pad. The square package matches the optical center with the mechanical center. This provides easy clustering flexibility and high packing density for a maximum flux density.
The color bins are defined for best fit to most signaling norms.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
1.0 W
|
High
|
124 lm
|
43.8 cd
|
377 mW
|
134 mW/sr
|
110 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.02 mm
|
|
OSRAM Advanced Power TOPLED™, LCY G6SP
|
Advanced Power TOPLED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.46 W
|
Mid
|
18.7 lm
|
6.28 cd
|
63.9 mW
|
21.4 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Black Flat, LCY H9PP
|
OSLON Black Flat is a new small size high-flux LED for slim designs. The black package stands for high stability.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
1.0 W
|
High
|
73 lm
|
24.3 cd
|
260 mW
|
86.3 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.75 mm
|
3.75 mm
|
0.7 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LD MVSG
|
Small size high-flux LED for slim designs
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
0.061 W
|
Low
|
1.2 lm
|
0.426 cd
|
27.5 mW
|
9.75 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.2 mm
|
1.8 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE A P0MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
17.0 W
|
Ultra High
|
1140 lm
|
376 cd
|
4690 mW
|
1550 mW/sr
|
120 °
|
7.6 mm
|
6.8 mm
|
1.4 mm
|
5.91 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE A P1MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
35.0 W
|
Ultra High
|
2270 lm
|
759 cd
|
9360 mW
|
3140 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
11.8 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE A P2MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
70.0 W
|
Ultra High
|
4400 lm
|
1470 cd
|
18200 mW
|
6090 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE A P3MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
100.0 W
|
Ultra High
|
6630 lm
|
2220 cd
|
27400 mW
|
9180 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
34.5 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE A Q7WP
|
High luminance device in a reliable ceramic package configuration dedicated for RGB projection systems in automotive enviroments.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
3.1 W
|
High
|
470 lm
|
169 cd
|
1940 mW
|
698 mW/sr
|
120 °
|
-40 °C
|
105 °C
|
5.75 mm
|
4.68 mm
|
1.25 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE A Q7WR
|
The OSTAR Projection LE A Q7WR is specifically designed for automotive head-up applications using a DMD.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
3.1 W
|
High
|
425 lm
|
153 cd
|
1760 mW
|
632 mW/sr
|
120 °
|
-40 °C
|
105 °C
|
5.75 mm
|
4.68 mm
|
1.25 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE A Q8WP
|
Compact light source in SMT technology, glass window on top, RoHS compliant.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
3.2 W
|
High
|
215 lm
|
77.3 cd
|
889 mW
|
319 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.9 mm
|
3.65 mm
|
1.2 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE B P0MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
40.0 W
|
Ultra High
|
398 lm
|
130 cd
|
11400 mW
|
3720 mW/sr
|
120 °
|
7.6 mm
|
6.8 mm
|
1.4 mm
|
42.9 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE B P1MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
80.0 W
|
Ultra High
|
680 lm
|
221 cd
|
19400 mW
|
6310 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
73.3 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE B P2MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
160.0 W
|
Ultra High
|
970 lm
|
316 cd
|
27700 mW
|
9010 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE B P3MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
130.0 W
|
Ultra High
|
1430 lm
|
464 cd
|
40700 mW
|
13200 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE B Q7WP
|
High luminance device in a reliable ceramic package configuration dedicated for RGB projection systems in automotive enviroments.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
4.1 W
|
High
|
179 lm
|
64.4 cd
|
4080 mW
|
1470 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
5.75 mm
|
4.68 mm
|
1.25 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE B Q7WR
|
The OSTAR Projection LE B Q7WR is specifically designed for automotive head-up applications using a DMD.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
4.1 W
|
High
|
168 lm
|
57.9 cd
|
3830 mW
|
1320 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
5.75 mm
|
4.68 mm
|
1.25 mm
|
14.6 µmol/s
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE B Q8WP
|
High luminance device in a reliable ceramic package
configuration dedicated for RGB projection systems
in automotive environments.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
4.1 W
|
High
|
89.9 lm
|
32.3 cd
|
2050 mW
|
735 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.9 mm
|
3.65 mm
|
1.2 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE CG P0AQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
40.0 W
|
Ultra High
|
3900 lm
|
1260 cd
|
8450 mW
|
2730 mW/sr
|
120 °
|
7.6 mm
|
6.8 mm
|
1.4 mm
|
17.7 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE CG P1AQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
80.0 W
|
Ultra High
|
7750 lm
|
2500 cd
|
16800 mW
|
5420 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
35.3 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE CG P2AQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
160.0 W
|
Ultra High
|
10200 lm
|
3280 cd
|
22000 mW
|
7100 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE CG P3AQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
130.0 W
|
Ultra High
|
15100 lm
|
4860 cd
|
32600 mW
|
10500 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE CG Q7WP
|
High luminance device in a reliable ceramic package configuration dedicated for RGB projection systems in automotive enviroments.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
4.1 W
|
High
|
1460 lm
|
331 cd
|
3200 mW
|
726 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
5.75 mm
|
4.68 mm
|
1.25 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE CG Q7WR
|
The OSTAR Projection LE CG Q7WR is specifically designed for automotive head-up applications using a DMD.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
4.1 W
|
High
|
1360 lm
|
308 cd
|
2970 mW
|
674 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
5.75 mm
|
4.68 mm
|
1.25 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE CG Q8WP
|
High luminance device in a reliable ceramic package
configuration dedicated for RGB projection systems
in automotive environments.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
4.1 W
|
High
|
730 lm
|
166 cd
|
1600 mW
|
363 mW/sr
|
130 °
|
-40 °C
|
125 °C
|
3.9 mm
|
3.65 mm
|
1.2 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE D P0MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
40.0 W
|
Ultra High
|
195 lm
|
63.3 cd
|
14300 mW
|
4630 mW/sr
|
120 °
|
7.6 mm
|
6.8 mm
|
1.4 mm
|
51.5 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE D P1MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
80.0 W
|
Ultra High
|
389 lm
|
127 cd
|
28500 mW
|
9270 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
103 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE D P2MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
160.0 W
|
Ultra High
|
477 lm
|
155 cd
|
35000 mW
|
11400 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE D P3MQ
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
130.0 W
|
Ultra High
|
651 lm
|
212 cd
|
47700 mW
|
15500 mW/sr
|
120 °
|
27.0 mm
|
15.5 mm
|
1.5 mm
|
172 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE R Q8WP
|
Compact light source in SMT technology, glass window on top, RoHS compliant
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
3.0 W
|
High
|
168 lm
|
60.4 cd
|
940 mW
|
338 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.9 mm
|
3.65 mm
|
1.2 mm
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE T Q7WR
|
The OSTAR Projection LE T Q7WR is specifically designed for automotive head-up applications using a DMD.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
3.9 W
|
High
|
815 lm
|
272 cd
|
1670 mW
|
559 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
5.75 mm
|
4.68 mm
|
1.25 mm
|
3.58 µmol/s
|
AEC-Q102
|
|
OSRAM OSRAM OSTAR™ Projection Compact, LE T Q8WP
|
Compact light source in SMT technology, glass window on top, RoHS compliant
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
3.9 W
|
High
|
337 lm
|
115 cd
|
680 mW
|
232 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.9 mm
|
3.65 mm
|
1.2 mm
|
|
OSRAM Mini TOPLED™, LG M67K
|
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.0038 W
|
Low
|
0.014 lm
|
0.00445 cd
|
0.0219 mW
|
0.00696 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LG P47K
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.0038 W
|
Low
|
0.0177 lm
|
0.00562 cd
|
0.0284 mW
|
0.009 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM Chip LED 0603, LG Q976.01
|
The Chip LED 0603 is the product of choice for low power status indication in electronics. The small package size allows compact designs, like 7-segment displays, symbol backlighting or button and switch illumination in control panels. The high brightness of the LED ensures good visibility at any time.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.04 W
|
Low
|
0.129 lm
|
0.0315 cd
|
0.205 mW
|
0.0501 mW/sr
|
140 °
|
-40 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.7 mm
|
|
OSRAM Chip LED 0805, LG R971
|
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.044 W
|
Low
|
0.141 lm
|
0.0261 cd
|
0.239 mW
|
0.0443 mW/sr
|
160 °
|
-30 °C
|
85 °C
|
2.0 mm
|
1.3 mm
|
0.8 mm
|
|
OSRAM TOPLED™, LG T676
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.042 W
|
Low
|
0.292 lm
|
0.0925 cd
|
0.47 mW
|
0.149 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LG T67K
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.0038 W
|
Low
|
0.0232 lm
|
0.00738 cd
|
0.0363 mW
|
0.0115 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Micro SIDELED™ 3010, LG Y876
|
Micro SIDELED is a SMT LED with side emission. Due to its low package height it is ideal for applications in limited space environments.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.042 W
|
Low
|
0.247 lm
|
0.0785 cd
|
0.387 mW
|
0.123 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
1.1 mm
|
1.2 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Signal, LJ CRBP.01
|
The OSLON™ Signal combines a compact form factor with high efficiency and electrically insulated thermal pad. The square package matches the optical center with the mechanical center. This provides easy clustering flexibility and high packing density for a maximum flux density.
The color bins are defined for best fit to most signaling norms.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.74 W
|
High
|
95.5 lm
|
31.4 cd
|
570 mW
|
188 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.12 mm
|
|
OSRAM Mini TOPLED™, LO M676
|
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.701 lm
|
0.223 cd
|
1.97 mW
|
0.626 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LO M67F.01
|
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.043 W
|
Low
|
3.68 lm
|
1.18 cd
|
10.4 mW
|
3.35 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LO M67K
|
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.0036 W
|
Low
|
0.0495 lm
|
0.0157 cd
|
0.138 mW
|
0.0436 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LO P476
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.78 lm
|
0.248 cd
|
2.2 mW
|
0.697 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LO P47F
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.068 W
|
Low
|
6 lm
|
1.96 cd
|
16.5 mW
|
5.38 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LO P47K
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.0036 W
|
Low
|
0.0495 lm
|
0.0157 cd
|
0.135 mW
|
0.0429 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM Chip LED 0603, LO Q976.01
|
The Chip LED 0603 is the product of choice for low power status indication in electronics. The small package size allows compact designs, like 7-segment displays, symbol backlighting or button and switch illumination in control panels. The high brightness of the LED ensures good visibility at any time.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.592 lm
|
0.146 cd
|
1.5 mW
|
0.371 mW/sr
|
140 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.7 mm
|
|
OSRAM Chip LED 0805, LO R976
|
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.879 lm
|
0.163 cd
|
2.44 mW
|
0.452 mW/sr
|
160 °
|
-30 °C
|
85 °C
|
2.0 mm
|
1.3 mm
|
0.8 mm
|
|
OSRAM TOPLED™, LO T676
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.711 lm
|
0.234 cd
|
2 mW
|
0.657 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LO T67F.01
|
SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality and extreme robust product for all kind of applications. With the latest generation (.01) we will continue this successful path.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.043 W
|
Low
|
5.24 lm
|
1.68 cd
|
14.8 mW
|
4.76 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LO T67K
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.0036 W
|
Low
|
0.0553 lm
|
0.0176 cd
|
0.151 mW
|
0.048 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Micro SIDELED™ 3010, LO Y876
|
Micro SIDELED is a SMT LED with side emission. Due to its low package height it is ideal for applications in limited space environments.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.701 lm
|
0.223 cd
|
1.91 mW
|
0.607 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
1.1 mm
|
1.2 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LP T675
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
0.062 W
|
Low
|
0.186 lm
|
0.059 cd
|
0.279 mW
|
0.0886 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LP T676
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
0.042 W
|
Low
|
0.078 lm
|
0.0248 cd
|
0.118 mW
|
0.0376 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM SIDELED™, LR A67F
|
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.06 W
|
Low
|
5.29 lm
|
1.68 cd
|
30.6 mW
|
9.71 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
4.0 mm
|
4.0 mm
|
3.6 mm
|
|
OSRAM Power SIDELED™, LR B6SP
|
Power SIDELED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.31 W
|
Mid
|
29.2 lm
|
9.8 cd
|
167 mW
|
55.9 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
4.8 mm
|
4.8 mm
|
3.8 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LR E67F
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.11 W
|
Low
|
8.19 lm
|
2.6 cd
|
47.4 mW
|
15 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0137 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LR E67F.01
|
PowerTOPLED, a powerful member of the TOPLED
family. Thanks to their high luminous efficacy, the
LEDs are ideal for rear light clusters and indicators
on vehicles and for display panels for traffic control
systems.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.11 W
|
Low
|
8.57 lm
|
2.8 cd
|
41.6 mW
|
13.6 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0147 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LR E6SF
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.11 W
|
Low
|
7.58 lm
|
2.47 cd
|
43.8 mW
|
14.3 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM Advanced Power TOPLED™, LR G6SP.01
|
Latest version of Advanced Power TOPLED with increased brightness and improved thermal management.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.31 W
|
Mid
|
17.3 lm
|
5.8 cd
|
98.6 mW
|
33.1 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Advanced Power TOPLED™, LR G6SP.02
|
The Advanced Power TOPLED.02 (APT.02) features ams OSRAM’s state-of-the-art generation of PLCC 6 packages, which have set a market standard in the mid power LED world and were decades ago the first of its kind. With its very robust design, the APT.02 family can withstand harsh environmental conditions and offers the highest level of processability. Containing our latest InGaAlP-chip technology the APT.02 keeps its market leading brightness performance and offers a wide range of available bins with a high luminous efficiency and an excellent thermal resistance.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.31 W
|
Mid
|
24.3 lm
|
8.15 cd
|
138 mW
|
46.3 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Black, LR H9GP
|
OSLON Black Series combines thermal stability with high performance and reliability in a compact black package. It has a metal lead frame and a tried and tested lens design. The LED can be used wherever there are large fluctuations in temperature and a large amount of light is needed from a small area.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.75 W
|
High
|
60.5 lm
|
27.8 cd
|
345 mW
|
159 mW/sr
|
90 °
|
-40 °C
|
125 °C
|
3.75 mm
|
3.75 mm
|
2.29 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Black Flat, LR H9PP
|
OSLON Black Flat is a new small size high-flux LED for slim designs. The black package stands for high stability.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.75 W
|
High
|
55 lm
|
18.3 cd
|
313 mW
|
104 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.75 mm
|
3.75 mm
|
0.5 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LR P47F
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.066 W
|
Low
|
3.72 lm
|
1.18 cd
|
20.6 mW
|
6.52 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM Chip LED 0603, LR Q976.01
|
The Chip LED 0603 is the product of choice for low power status indication in electronics. The small package size allows compact designs, like 7-segment displays, symbol backlighting or button and switch illumination in control panels. The high brightness of the LED ensures good visibility at any time.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.04 W
|
Low
|
0.482 lm
|
0.118 cd
|
2.29 mW
|
0.56 mW/sr
|
140 °
|
-40 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.7 mm
|
|
OSRAM TOPLED™ Black, LR T64F
|
TOPLED Black is especially designed for variable message signs (VMS) and price changers. The black package offers premium contrast for display panels.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.039 W
|
Low
|
1.17 lm
|
3.33 cd
|
6.78 mW
|
19.3 mW/sr
|
30 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.65 mm
|
24.7 µmol/s
|
|
OSRAM TOPLED™ Black, LR T66F
|
TOPLED Black is especially designed for variable message signs (VMS) and price changers. The black package offers premium contrast for display panels.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.039 W
|
Low
|
1.71 lm
|
2.33 cd
|
9.88 mW
|
13.5 mW/sr
|
55 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.5 mm
|
|
OSRAM TOPLED™, LR T67F.01
|
SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality and extreme robust product for all kind of applications. With the latest generation (.01) we will continue this successful path.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.043 W
|
Low
|
3.08 lm
|
0.98 cd
|
17.4 mW
|
5.54 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ Black Surface, LR T68F
|
First SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.043 W
|
Low
|
3.72 lm
|
1.18 cd
|
20.6 mW
|
6.52 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM FIREFLY™ 0402, LR VH9F
|
The FIREFLY is designed for use in consumer applications. Due to its low height and optical characteristics it is optimized for flat indirect backlighting of switches.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.0095 W
|
Low
|
0.732 lm
|
0.157 cd
|
3.72 mW
|
0.798 mW/sr
|
140 °
|
150 °
|
-40 °C
|
85 °C
|
1.0 mm
|
0.55 mm
|
0.3 mm
|
|
OSRAM Micro SIDELED™ 3010, LR Y8SF
|
Micro SIDELED is a SMT LED with side emission. Due to its low package height it is ideal for applications in limited space environments.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.043 W
|
Low
|
2.39 lm
|
0.785 cd
|
13.2 mW
|
4.34 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
1.1 mm
|
1.2 mm
|
|
OSRAM SIDELED™, LS A67F
|
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.06 W
|
Low
|
5.14 lm
|
1.4 cd
|
39.6 mW
|
10.8 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
4.0 mm
|
4.0 mm
|
3.6 mm
|
|
OSRAM Power SIDELED™, LS B6SP
|
Power SIDELED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.3 W
|
Mid
|
18.7 lm
|
6.28 cd
|
158 mW
|
53.1 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
4.8 mm
|
4.8 mm
|
3.8 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™ Lens, LS E63F
|
PowerTOPLED with lens, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.11 W
|
Low
|
5.9 lm
|
20.5 cd
|
45.4 mW
|
158 mW/sr
|
30 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.8 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™ Lens, LS E65F
|
PowerTOPLED with lens, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.11 W
|
Low
|
7.73 lm
|
7 cd
|
59.6 mW
|
53.9 mW/sr
|
60 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.5 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LS E67F
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.11 W
|
Low
|
5.94 lm
|
1.95 cd
|
45.7 mW
|
15 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0104 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LS E67F.01
|
PowerTOPLED, a powerful member of the TOPLED
family. Thanks to their high luminous efficacy, the
LEDs are ideal for rear light clusters and indicators
on vehicles and for display panels for traffic control
systems.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.11 W
|
Low
|
6.27 lm
|
2.05 cd
|
49.4 mW
|
16.1 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.011 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LS E6SF
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.11 W
|
Low
|
5.97 lm
|
1.76 cd
|
46 mW
|
15.1 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM Advanced Power TOPLED™, LS G6SP.01
|
Latest version of Advanced Power TOPLED with increased brightness and improved thermal management.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.31 W
|
Mid
|
15.8 lm
|
5.3 cd
|
134 mW
|
44.8 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Advanced Power TOPLED™, LS G6SP.02
|
The Advanced Power TOPLED.02 (APT.02) features ams OSRAM’s state-of-the-art generation of PLCC 6 packages, which have set a market standard in the mid power LED world and were decades ago the first of its kind. With its very robust design, the APT.02 family can withstand harsh environmental conditions and offers the highest level of processability. Containing our latest InGaAlP-chip technology the APT.02 keeps its market leading brightness performance and offers a wide range of available bins with a high luminous efficiency and an excellent thermal resistance.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.3 W
|
Mid
|
18.6 lm
|
6.25 cd
|
106 mW
|
35.5 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Black Flat, LS H9PP
|
OSLON Black Flat is a new small size high-flux LED for slim designs. The black package stands for high stability.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.75 W
|
High
|
42.5 lm
|
14.1 cd
|
315 mW
|
105 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.75 mm
|
3.75 mm
|
0.5 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LS M676
|
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.04 W
|
Low
|
0.441 lm
|
0.14 cd
|
3.88 mW
|
1.23 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LS M67F.01
|
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.043 W
|
Low
|
2.18 lm
|
0.7 cd
|
18.3 mW
|
5.88 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LS M67K
|
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.0036 W
|
Low
|
0.0277 lm
|
0.00878 cd
|
0.23 mW
|
0.073 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LS P47F
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.066 W
|
Low
|
3.09 lm
|
0.98 cd
|
23.8 mW
|
7.55 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LS P47K
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.0036 W
|
Low
|
0.0221 lm
|
0.007 cd
|
0.159 mW
|
0.0504 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM Chip LED 0603, LS Q976.01
|
The Chip LED 0603 is the product of choice for low power status indication in electronics. The small package size allows compact designs, like 7-segment displays, symbol backlighting or button and switch illumination in control panels. The high brightness of the LED ensures good visibility at any time.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.04 W
|
Low
|
0.28 lm
|
0.07 cd
|
1.93 mW
|
0.481 mW/sr
|
140 °
|
-40 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.7 mm
|
|
OSRAM Chip LED 0805, LS R976
|
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.04 W
|
Low
|
0.562 lm
|
0.104 cd
|
4.68 mW
|
0.865 mW/sr
|
160 °
|
-30 °C
|
85 °C
|
2.0 mm
|
1.3 mm
|
0.8 mm
|
|
OSRAM TOPLED™, LS T676
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.04 W
|
Low
|
0.445 lm
|
0.146 cd
|
3.91 mW
|
1.28 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LS T67F.01
|
SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality and extreme robust product for all kind of applications. With the latest generation (.01) we will continue this successful path.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.043 W
|
Low
|
3.68 lm
|
1.18 cd
|
30.9 mW
|
9.91 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LS T67K
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.0036 W
|
Low
|
0.0355 lm
|
0.0113 cd
|
0.295 mW
|
0.0936 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Micro SIDELED™ 3010, LS Y876
|
Micro SIDELED is a SMT LED with side emission. Due to its low package height it is ideal for applications in limited space environments.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.04 W
|
Low
|
0.441 lm
|
0.14 cd
|
3.46 mW
|
1.1 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
1.1 mm
|
1.2 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Signal, LT CRBP.01
|
The OSLON™ Signal combines a compact form factor with high efficiency and electrically insulated thermal pad. The square package matches the optical center with the mechanical center. This provides easy clustering flexibility and high packing density for a maximum flux density.
The color bins are defined for best fit to most signaling norms.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.93 W
|
High
|
139 lm
|
47.4 cd
|
288 mW
|
98.5 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.02 mm
|
|
OSRAM Power TOPLED™, LT E6SG
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.084 W
|
Low
|
5.97 lm
|
1.96 cd
|
11.7 mW
|
3.84 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM Mini TOPLED™, LT M67D
|
Small size high-flux LED for slim designs
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.0035 W
|
Low
|
0.662 lm
|
0.21 cd
|
1.3 mW
|
0.412 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LT MVSG
|
Small size high-flux LED for slim designs
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.025 W
|
Low
|
4.55 lm
|
1.6 cd
|
8.88 mW
|
3.12 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.2 mm
|
1.8 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LT PWSG
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.053 W
|
Low
|
8 lm
|
2.67 cd
|
15.6 mW
|
5.22 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
|
OSRAM Chip LED 0603, LT Q99G.01
|
The Chip LED 0603 is the product of choice for low power status indication in electronics. The small package size allows compact designs, like 7-segment displays, symbol backlighting or button and switch illumination in control panels. The high brightness of the LED ensures good visibility at any time.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.015 W
|
Low
|
1.16 lm
|
0.248 cd
|
2.41 mW
|
0.515 mW/sr
|
140 °
|
-40 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.7 mm
|
|
OSRAM Chip LED 0402, LT QH9G
|
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.014 W
|
Low
|
1.09 lm
|
0.27 cd
|
2.26 mW
|
0.561 mW/sr
|
170 °
|
115 °
|
-40 °C
|
85 °C
|
1.0 mm
|
0.5 mm
|
0.35 mm
|
|
OSRAM TOPLED™ Black, LT T64G
|
TOPLED Black is especially designed for variable message signs (VMS) and price changers. The black package offers premium contrast for display panels.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.052 W
|
Low
|
5.44 lm
|
10.9 cd
|
10.6 mW
|
21.3 mW/sr
|
30 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.65 mm
|
|
OSRAM TOPLED™ Black, LT T66G
|
TOPLED Black is especially designed for variable message signs (VMS) and price changers. The black package offers premium contrast for display panels.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.054 W
|
Low
|
6.64 lm
|
6.75 cd
|
13 mW
|
13.2 mW/sr
|
55 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.35 mm
|
|
OSRAM TOPLED™, LT T67D
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.013 W
|
Low
|
1.68 lm
|
0.533 cd
|
3.42 mW
|
1.09 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LT TTSD
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.027 W
|
Low
|
2.47 lm
|
0.785 cd
|
5.05 mW
|
1.6 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM FIREFLY™ 0402, LT VH9G
|
The FIREFLY is designed for use in mobile communication applications. Due to its low height and optical characteristics it is optimized for flat backlighting of keypads.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.015 W
|
Low
|
1.04 lm
|
0.27 cd
|
2.17 mW
|
0.561 mW/sr
|
110 °
|
155 °
|
-40 °C
|
85 °C
|
1.0 mm
|
0.55 mm
|
0.3 mm
|
|
OSRAM Micro SIDELED™ 2808, LT Y1SG
|
Micro SIDELED is a SMT LED with side emission. Due to its low package height it is ideal for applications in limited space environments.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.057 W
|
Low
|
11.2 lm
|
3.15 cd
|
22.3 mW
|
6.25 mW/sr
|
120 °
|
-40 °C
|
85 °C
|
2.8 mm
|
1.2 mm
|
0.8 mm
|
|
OSRAM OSLON™ Signal, LV CRBP.01
|
The OSLON™ Signal combines a compact form factor with high efficiency and electrically insulated thermal pad. The square package matches the optical center with the mechanical center. This provides easy clustering flexibility and high packing density for a maximum flux density.
The color bins are defined for best fit to most signaling norms.
|
LEDs
|
Color LEDs
|
Verde (495-512 nm)
|
1.0 W
|
High
|
111 lm
|
37.3 cd
|
550 mW
|
185 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.02 mm
|
|
OSRAM TOPLED™ Black, LV T64G
|
TOPLED Black is especially designed for variable message signs (VMS) and price changers. The black package offers premium contrast for display panels.
|
LEDs
|
Color LEDs
|
Verde (495-512 nm)
|
0.054 W
|
Low
|
3.18 lm
|
6.38 cd
|
9.73 mW
|
19.5 mW/sr
|
30 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.65 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ Black Surface, LW TWTG.BB
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
White
|
0.061 W
|
Low
|
110 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM SIDELED™, LY A67F
|
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.062 W
|
Low
|
6.26 lm
|
2.05 cd
|
12.6 mW
|
4.15 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
4.0 mm
|
4.0 mm
|
3.6 mm
|
|
OSRAM OSLON™ SX, LY CN5M
|
The OSLON™ SX combine a compact size (small footprint: 3x3mm) with a high efficiency and a electrically insulated thermal pad.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.32 W
|
Mid
|
19.6 lm
|
14.5 cd
|
39.2 mW
|
29 mW/sr
|
60 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.43 mm
|
|
OSRAM Power TOPLED™ Lens, LY E63F
|
PowerTOPLED with lens, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
8.7 lm
|
30.2 cd
|
17.5 mW
|
60.9 mW/sr
|
30 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.8 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™ Lens, LY E65F
|
PowerTOPLED with lens, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
10.2 lm
|
9.25 cd
|
20.6 mW
|
18.7 mW/sr
|
60 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.5 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LY E67F
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
9.44 lm
|
3.1 cd
|
19.1 mW
|
6.26 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0153 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LY E67F.01
|
PowerTOPLED, a powerful member of the TOPLED
family. Thanks to their high luminous efficacy, the
LEDs are ideal for rear light clusters and indicators
on vehicles and for display panels for traffic control
systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
9.84 lm
|
3.25 cd
|
19.6 mW
|
6.49 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
0.0161 µmol/s
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LY E6SF
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
10.7 lm
|
3.5 cd
|
21.5 mW
|
7.06 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM Power TOPLED™, LY ETSF
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
10.2 lm
|
3.36 cd
|
20.7 mW
|
6.78 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Advanced Power TOPLED™, LY G6SP
|
Advanced Power TOPLED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.32 W
|
Mid
|
26.1 lm
|
8.78 cd
|
52.3 mW
|
17.5 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Advanced Power TOPLED™, LY G6SP.02
|
The Advanced Power TOPLED.02 (APT.02) features ams OSRAM’s state-of-the-art generation of PLCC 6 packages, which have set a market standard in the mid power LED world and were decades ago the first of its kind. With its very robust design, the APT.02 family can withstand harsh environmental conditions and offers the highest level of processability. Containing our latest InGaAlP-chip technology the APT.02 keeps its market leading brightness performance and offers a wide range of available bins with a high luminous efficiency and an excellent thermal resistance.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.32 W
|
Mid
|
28 lm
|
9.4 cd
|
53.1 mW
|
17.8 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
0.0462 µmol/s
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LY M676
|
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
0.701 lm
|
0.223 cd
|
1.32 mW
|
0.419 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LY M67F.01
|
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.044 W
|
Low
|
2.76 lm
|
0.878 cd
|
5.27 mW
|
1.68 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LY M67K
|
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.0038 W
|
Low
|
0.0355 lm
|
0.0113 cd
|
0.069 mW
|
0.0219 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LY P47F
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.062 W
|
Low
|
4.78 lm
|
1.57 cd
|
9.65 mW
|
3.17 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM PointLED™, LY P47K
|
With a diameter of just 2 mm, the PointLED is one of the smallest packages in its class and achieves high luminous efficacies.
Due to its round and flat package, measuring only 0.775 mm high, it is ideal for application where space is a sensitive issue.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.0038 W
|
Low
|
0.0355 lm
|
0.0113 cd
|
0.0692 mW
|
0.022 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.4 mm
|
1.25 mm
|
0.83 mm
|
AEC-Q102
|
|
OSRAM Chip LED 0603, LY Q976.01
|
The Chip LED 0603 is the product of choice for low power status indication in electronics. The small package size allows compact designs, like 7-segment displays, symbol backlighting or button and switch illumination in control panels. The high brightness of the LED ensures good visibility at any time.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
0.453 lm
|
0.126 cd
|
0.87 mW
|
0.241 mW/sr
|
140 °
|
-40 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.7 mm
|
|
OSRAM Chip LED 0805, LY R976
|
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
0.879 lm
|
0.163 cd
|
1.71 mW
|
0.316 mW/sr
|
160 °
|
-30 °C
|
85 °C
|
2.0 mm
|
1.3 mm
|
0.8 mm
|
|
OSRAM TOPLED™ Black, LY T64F
|
TOPLED Black is especially designed for variable message signs (VMS) and price changers. The black package offers premium contrast for display panels.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
1.17 lm
|
3.33 cd
|
2.37 mW
|
6.73 mW/sr
|
30 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.65 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ Black, LY T66F
|
TOPLED Black is especially designed for variable message signs (VMS) and price changers. The black package offers premium contrast for display panels.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
1.81 lm
|
2.47 cd
|
3.66 mW
|
5 mW/sr
|
55 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
3.5 mm
|
|
OSRAM TOPLED™, LY T676
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
0.615 lm
|
0.202 cd
|
1.16 mW
|
0.38 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LY T67F.01
|
SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality and extreme robust product for all kind of applications. With the latest generation (.01) we will continue this successful path.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.044 W
|
Low
|
4.24 lm
|
1.35 cd
|
8.11 mW
|
2.58 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LY T67K
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.0036 W
|
Low
|
0.0441 lm
|
0.014 cd
|
0.0858 mW
|
0.0272 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™ Black Surface, LY T68F
|
First SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.044 W
|
Low
|
2.77 lm
|
0.878 cd
|
5.75 mW
|
1.82 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM Micro SIDELED™ 3010, LY Y876
|
Micro SIDELED is a SMT LED with side emission. Due to its low package height it is ideal for applications in limited space environments.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
0.701 lm
|
0.223 cd
|
1.32 mW
|
0.419 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
1.1 mm
|
1.2 mm
|
AEC-Q102
|
|
OSRAM Micro SIDELED™ 3010, LY Y8SF
|
Micro SIDELED is a SMT LED with side emission. Due to its low package height it is ideal for applications in limited space environments.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.044 W
|
Low
|
2.39 lm
|
0.785 cd
|
4.6 mW
|
1.51 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.0 mm
|
1.1 mm
|
1.2 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-00B202
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
3.3 W
|
High
|
50 lm
|
27.4 cd
|
1470 mW
|
807 mW/sr
|
90 °
|
-40 °C
|
150 °C
|
4.4 mm
|
4.4 mm
|
2.4 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-00DB00
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
3.2 W
|
High
|
58.2 lm
|
37.4 cd
|
1100 mW
|
706 mW/sr
|
80 °
|
-40 °C
|
150 °C
|
4.4 mm
|
4.4 mm
|
2.7 mm
|
4.24 µmol/s
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-00G102
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
2.9 W
|
High
|
215 lm
|
103 cd
|
493 mW
|
235 mW/sr
|
100 °
|
-40 °C
|
150 °C
|
4.4 mm
|
4.4 mm
|
2.4 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-00R102
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
2.6 W
|
High
|
180 lm
|
84.1 cd
|
900 mW
|
420 mW/sr
|
100 °
|
-40 °C
|
125 °C
|
4.4 mm
|
4.4 mm
|
2.4 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-00R202
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
2.5 W
|
High
|
89.7 lm
|
46.6 cd
|
1200 mW
|
555 mW/sr
|
100 °
|
-40 °C
|
125 °C
|
4.4 mm
|
4.4 mm
|
2.4 mm
|
6.54 µmol/s
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-00R302
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
2.3 W
|
High
|
1.21 lm
|
0.559 cd
|
975 mW
|
450 mW/sr
|
110 °
|
-40 °C
|
125 °C
|
4.4 mm
|
4.4 mm
|
2.4 mm
|
5.96 µmol/s
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-00UBN0
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Violet (380-440 nm)
|
2.6 W
|
High
|
34.3 lm
|
26 cd
|
1550 mW
|
1180 mW/sr
|
70 °
|
-30 °C
|
100 °C
|
4.4 mm
|
4.4 mm
|
2.7 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-00UVH0
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Ultraviolet (100-380 nm)
|
2.7 W
|
High
|
12.6 lm
|
9.88 cd
|
1430 mW
|
1120 mW/sr
|
75 °
|
-30 °C
|
85 °C
|
4.4 mm
|
4.4 mm
|
2.7 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ1-10B202
|
LZ1 Emitter on MCPCB<Return/>For emitter specification, please refer to the emitter datasheet LZ1-00B202.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
3.3 W
|
High
|
50 lm
|
90 °
|
-40 °C
|
150 °C
|
19.9 mm
|
19.9 mm
|
4.1 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00A108
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
7.0 W
|
Ultra High
|
470 lm
|
216 cd
|
940 mW
|
433 mW/sr
|
100 °
|
-40 °C
|
125 °C
|
7.0 mm
|
7.0 mm
|
3.7 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00B208
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
8.3 W
|
Ultra High
|
145 lm
|
65.1 cd
|
4270 mW
|
1920 mW/sr
|
100 °
|
-40 °C
|
150 °C
|
7.0 mm
|
7.0 mm
|
3.7 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00D108
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Violet (380-440 nm)
Blue (450-480 nm)
|
2.5 W
7.3 W
|
High
Ultra High
|
1300 mW
|
110 °
|
-40 °C
|
125 °C
|
7.0 mm
|
7.0 mm
|
3.75 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00DB0R
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
9.7 W
|
Ultra High
|
172 lm
|
60.9 cd
|
3200 mW
|
1140 mW/sr
|
115 °
|
-40 °C
|
150 °C
|
7.0 mm
|
7.0 mm
|
3.9 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00G108
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
8.1 W
|
Ultra High
|
640 lm
|
287 cd
|
1290 mW
|
580 mW/sr
|
100 °
|
-40 °C
|
150 °C
|
7.0 mm
|
7.0 mm
|
3.7 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00R108
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
6.8 W
|
Ultra High
|
500 lm
|
240 cd
|
2500 mW
|
1200 mW/sr
|
100 °
|
-40 °C
|
125 °C
|
7.0 mm
|
7.0 mm
|
3.7 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00R308
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Far Red (720-740 nm)
|
6.0 W
|
4.14 lm
|
1.9 cd
|
2800 mW
|
1290 mW/sr
|
110 °
|
-40 °C
|
125 °C
|
7.0 mm
|
7.0 mm
|
3.7 mm
|
17 µmol/s
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-00UBH0
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Violet (380-440 nm)
|
9.9 W
|
Ultra High
|
110 °
|
-30 °C
|
85 °C
|
7.0 mm
|
7.0 mm
|
3.9 mm
|
|
OSRAM LED ENGIN LuxiGen™, LZ4-04UVH0
|
Industry's most robust high power ceramic package with glass lens for high performance over life.
|
LEDs
|
Color LEDs
|
Ultraviolet (100-380 nm)
|
11.0 W
|
Ultra High
|
43.2 lm
|
16.6 cd
|
4900 mW
|
1880 mW/sr
|
110 °
|
-30 °C
|
100 °C
|
7.0 mm
|
7.0 mm
|
1.26 mm
|
|
OSRAM Metal Can TO18, SFH 464
|
GaAlAs Light Emitting Diode (660 nm)
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
0.11 W
|
Low
|
0.000000001 lm
|
0.000000002 cd
|
11 mW
|
16 mW/sr
|
-40 °C
|
80 °C
|
5.35 mm
|
5.35 mm
|
3.3 mm
|
|
OSRAM OSLON™ Square, GD CSBRM2.14
|
OSLON™ Square Deep Blue latest offering comes with a unique innovative radiation pattern, designed to illuminate plants evenly for uniform growth while reducing number of luminaires and lowering overall cost. Additionally, this high-power LED provides excellent reliability, long lifetime and low thermal resistance in a compact footprint.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
2.0 W
|
High
|
35.6 lm
|
6.1 cd
|
1470 mW
|
252 mW/sr
|
140 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.09 mm
|
|
OSRAM OSLON™ Square, GH CSBRM4.24
|
OSLON™ Square Hyper Red with the best value for highest PPF/W, is now available with a unique innovative radiation pattern, evenly illuminates plants for uniform growth while reducing number of luminaires and lowering overall cost. Additionally, this high-power LED provides excellent reliability, long lifetime and low thermal resistance in a compact footprint.
|
LEDs
|
Color LEDs
|
Hyper Red (635-666 nm)
|
1.4 W
|
High
|
59.9 lm
|
10.3 cd
|
1040 mW
|
180 mW/sr
|
140 °
|
-40 °C
|
125 °C
|
3.0 mm
|
3.0 mm
|
2.17 mm
|
|
OSRAM SYNIOS™ S2222, KB DDLM31.13
|
This square package with just 2mm outline combines best performance with a small footprint. A centralized chip allows an easy integration in optical systems. The availability of different main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.44 W
|
Mid
|
7.25 lm
|
2.48 cd
|
282 mW
|
96.5 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
|
OSRAM SYNIOS™ S2222, KR DDLM31.23
|
This square package with just 2mm outline combines best performance with a small footprint. A centralized chip allows an easy integration in optical systems. The availability of different main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.31 W
|
Mid
|
30 lm
|
10.1 cd
|
122 mW
|
41 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
|
OSRAM SYNIOS™ S2222, KS DDLM31.23
|
This square package with just 2mm outline combines best performance with a small footprint. A centralized chip allows an easy integration in optical systems. The availability of different main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.3 W
|
Mid
|
17.5 lm
|
5.87 cd
|
148 mW
|
49.7 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
|
OSRAM SYNIOS™ S2222, KT DDLM31.13
|
This square package with just 2mm outline combines best performance with a small footprint. A centralized chip allows an easy integration in optical systems. The availability of different main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.39 W
|
Mid
|
47.5 lm
|
15.9 cd
|
92.3 mW
|
31 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
|
OSRAM SYNIOS™ S2222, KY DDLM31.23
|
This square package with just 2mm outline combines best performance with a small footprint. A centralized chip allows an easy integration in optical systems. The availability of different main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.32 W
|
Mid
|
15 lm
|
5.03 cd
|
30 mW
|
10.1 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
|
OSRAM SYNIOS™ S2222, KY DDLM31.FY
|
This square package with just 2mm outline combines best performance with a small footprint. A centralized chip allows an easy integration in optical systems. The availability of different main colors and white points gives highest flexibility in various application areas.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.44 W
|
Mid
|
45.5 lm
|
15.6 cd
|
146 mW
|
50.1 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
2.25 mm
|
2.25 mm
|
0.6 mm
|
|
OSRAM Advanced Power TOPLED™, LA G6SP
|
Advanced Power TOPLED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.3 W
|
Mid
|
26.1 lm
|
8.78 cd
|
106 mW
|
35.7 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
0.0456 µmol/s
|
AEC-Q102
|
|
OSRAM Chip LED 0603, LB Q39E
|
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.014 W
|
Low
|
0.18 lm
|
0.0458 cd
|
2.28 mW
|
0.579 mW/sr
|
170 °
|
130 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM Chip LED 0603, LB Q39G
|
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.014 W
|
Low
|
0.21 lm
|
0.0533 cd
|
2.65 mW
|
0.674 mW/sr
|
170 °
|
130 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM Chip LED 0603, LG Q396
|
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.288 lm
|
0.0785 cd
|
0.456 mW
|
0.124 mW/sr
|
150 °
|
120 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM TOPLED™, LG T67F
|
First SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.042 W
|
Low
|
0.711 lm
|
0.234 cd
|
1.12 mW
|
0.367 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Chip LED 0603, LO Q976
|
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.679 lm
|
0.126 cd
|
1.89 mW
|
0.349 mW/sr
|
160 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.8 mm
|
|
OSRAM Advanced Power TOPLED™, LR G6SP
|
Advanced Power TOPLED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.29 W
|
Mid
|
18.9 lm
|
6.35 cd
|
108 mW
|
36.2 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Advanced Power TOPLED™, LS G6SP
|
Advanced Power TOPLED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.3 W
|
Mid
|
14.7 lm
|
4.95 cd
|
109 mW
|
36.7 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.3 mm
|
3.4 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Chip LED 0603, LS Q976
|
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.04 W
|
Low
|
0.265 lm
|
0.058 cd
|
2.2 mW
|
0.482 mW/sr
|
160 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.8 mm
|
|
OSRAM Chip LED 0603, LT Q39E
|
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.014 W
|
Low
|
1.01 lm
|
0.252 cd
|
2.11 mW
|
0.524 mW/sr
|
170 °
|
130 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM Chip LED 0603, LT Q39G
|
|
LEDs
|
Color LEDs
|
True Green (513-545 nm)
|
0.014 W
|
Low
|
1.01 lm
|
0.252 cd
|
2.11 mW
|
0.524 mW/sr
|
170 °
|
130 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM Chip LED 0603, LY Q396
|
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.268 lm
|
0.073 cd
|
0.515 mW
|
0.14 mW/sr
|
150 °
|
120 °
|
-30 °C
|
85 °C
|
1.6 mm
|
0.8 mm
|
0.4 mm
|
|
OSRAM OSLON™ Pure 1010, GD VJLPE1.14
|
Industry most compact high power chip-scale package LED with high performance, superior robustness and long lifetime.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
2.1 W
|
High
|
31.6 lm
|
10.1 cd
|
1100 mW
|
352 mW/sr
|
120 °
|
-40 °C
|
85 °C
|
1.08 mm
|
1.08 mm
|
0.36 mm
|
|
OSRAM OSLON™ Pure 1010, GR VJLPE1.F3
|
Industry most compact high power chip-scale package LED with high performance, superior robustness and long lifetime.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
2.1 W
|
High
|
45.5 lm
|
13.5 cd
|
310 mW
|
91.9 mW/sr
|
120 °
|
-40 °C
|
85 °C
|
1.08 mm
|
1.08 mm
|
0.36 mm
|
|
OSRAM TOPLED™ E1608, KG DELLS1.22
|
The TOPLED E1608 expands ams OSRAM’ low power portfolio by offering one of the smallest LED Industry standard footprints in a highly reliable and well proven package concept.
Its outstanding performance is suitable for a huge variety of applications especially automotive interior where a small package design with excellent reliability is needed. The TOPLED E1608 is available in different colors and brightness levels.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.0038 W
|
Low
|
0.0235 lm
|
0.0071 cd
|
0.0368 mW
|
0.0111 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
1.6 mm
|
0.8 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KR DMLQ31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KR DMLQ31.23 product is meant to provide superior light quality in ½ mm² chip size class.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.81 W
|
High
|
65 lm
|
20.9 cd
|
370 mW
|
119 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KS DMLQ31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KS DMLQ31.23 product is meant to provide superior light quality in ½ mm² chip size class.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.81 W
|
High
|
42.5 lm
|
13.7 cd
|
315 mW
|
101 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Compact PL, KY CELNM1.FY
|
Compact light source with isolated thermal pad for improved heat dissipation and small z-tolerance (+/- 35 µm).
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
3.0 W
|
High
|
212 lm
|
70.5 cd
|
602 mW
|
200 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
1.9 mm
|
1.5 mm
|
0.74 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KY DMLQ31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KY DMLQ31.23 product is meant to provide superior light quality in ½ mm² chip size class.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.83 W
|
High
|
60.5 lm
|
19.5 cd
|
121 mW
|
38.9 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SYNIOS™ P2720, KY DMLS31.23
|
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KY DMLS31.23 product is meant to provide superior light quality in 1 mm² chip size class.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
1.8 W
|
High
|
99.5 lm
|
32 cd
|
199 mW
|
64 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
2.75 mm
|
2.0 mm
|
0.6 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, LA L296
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.04 W
|
Low
|
0.574 lm
|
0.113 cd
|
2.37 mW
|
0.465 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM Mini TOPLED™, LA M67F
|
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.043 W
|
Low
|
3.82 lm
|
1.26 cd
|
15.5 mW
|
5.07 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
|
OSRAM TOPLED™, LA T67F
|
SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Amber (609-624 nm)
|
0.039 W
|
Low
|
4.65 lm
|
1.48 cd
|
18.8 mW
|
5.96 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LB T673
|
TOPLED, SMT LED with integrated reflector. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.031 W
|
Low
|
0.134 lm
|
0.0425 cd
|
1.85 mW
|
0.586 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Mini TOPLED™, LCB M67C
|
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.03 W
|
Low
|
0.662 lm
|
0.21 cd
|
2.7 mW
|
0.856 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
|
OSRAM Mini TOPLED™, LCB M67S
|
|
LEDs
|
Color LEDs
|
Blue (450-480 nm)
|
0.031 W
|
Low
|
0.277 lm
|
0.0878 cd
|
3.79 mW
|
1.2 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
|
OSRAM SMARTLED™ 0603, LG L29K
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Green (565-575 nm)
|
0.0034 W
|
Low
|
0.0179 lm
|
0.0035 cd
|
0.0279 mW
|
0.00547 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM Power TOPLED™, LO E67F
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.11 W
|
Low
|
11.3 lm
|
3.7 cd
|
31 mW
|
10.2 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LO E6SF
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.11 W
|
Low
|
8.98 lm
|
2.95 cd
|
24.7 mW
|
8.1 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
|
OSRAM SMARTLED™ 0603, LO L296
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.04 W
|
Low
|
0.687 lm
|
0.135 cd
|
1.87 mW
|
0.367 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM SMARTLED™ 0603, LO L29K
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.0036 W
|
Low
|
0.0448 lm
|
0.00878 cd
|
0.125 mW
|
0.0244 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM Mini TOPLED™, LO M67F
|
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.043 W
|
Low
|
3.61 lm
|
1.18 cd
|
9.93 mW
|
3.24 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
|
OSRAM TOPLED™, LO T67F
|
First SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Orange (600-609 nm)
|
0.043 W
|
Low
|
3.96 lm
|
1.26 cd
|
10.9 mW
|
3.45 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, LP L296
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
0.04 W
|
Low
|
0.0603 lm
|
0.0118 cd
|
0.0906 mW
|
0.0177 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM TOPLED™, LP T67F
|
First SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Pure Green (554-566 nm)
|
0.042 W
|
Low
|
0.317 lm
|
0.104 cd
|
0.476 mW
|
0.156 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM TOPLED™, LR T67F
|
First SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
0.041 W
|
Low
|
2.92 lm
|
0.925 cd
|
16.1 mW
|
5.12 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, LS L296
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.04 W
|
Low
|
0.357 lm
|
0.07 cd
|
2.8 mW
|
0.549 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM SMARTLED™ 0603, LS L29K
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.0036 W
|
Low
|
0.0227 lm
|
0.00445 cd
|
0.189 mW
|
0.037 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM Mini TOPLED™, LS M67F
|
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.041 W
|
Low
|
1.91 lm
|
0.628 cd
|
14.7 mW
|
4.84 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
|
OSRAM TOPLED™, LS T67F
|
First SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Super Red (627-639 nm)
|
0.041 W
|
Low
|
2.32 lm
|
0.738 cd
|
17.9 mW
|
5.68 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM Power SIDELED™, LY B6SP
|
Power SIDELED features a compact package with a wide brightness range and high luminous efficiency.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.32 W
|
Mid
|
25 lm
|
8.4 cd
|
50 mW
|
16.8 mW/sr
|
120 °
|
-40 °C
|
110 °C
|
4.8 mm
|
4.8 mm
|
3.8 mm
|
AEC-Q102
|
|
OSRAM Power TOPLED™, LY E67B
|
PowerTOPLED, a powerful member of the TOPLED family. Thanks to their high luminous efficacy, the LEDs are ideal for rear light clusters and indicators on vehicles and for display panels for traffic control systems.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.11 W
|
Low
|
2.77 lm
|
0.878 cd
|
5.72 mW
|
1.82 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Black, LY H9GP
|
OSLON Black Series combines thermal stability with high performance and reliability in a compact black package. It has a metal lead frame and a tried and tested lens design. The LED can be used wherever there are large fluctuations in temperature and a large amount of light is needed from a small area.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.79 W
|
High
|
68 lm
|
31.3 cd
|
136 mW
|
62.5 mW/sr
|
90 °
|
-40 °C
|
125 °C
|
3.75 mm
|
3.75 mm
|
2.29 mm
|
AEC-Q102
|
|
OSRAM OSLON™ Black Flat, LY H9PP
|
OSLON Black Flat is a new small size high-flux LED for slim designs. The black package stands for high stability.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.79 W
|
High
|
60.5 lm
|
20.1 cd
|
121 mW
|
40.2 mW/sr
|
120 °
|
-40 °C
|
125 °C
|
3.75 mm
|
3.75 mm
|
0.5 mm
|
AEC-Q102
|
|
OSRAM SMARTLED™ 0603, LY L296
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.04 W
|
Low
|
0.574 lm
|
0.113 cd
|
1.08 mW
|
0.212 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM SMARTLED™ 0603, LY L29K
|
The innovative SMARTLED 0603 joins the successful family of TOPLED. Invested with the same high quality, its unique features are due to set new standards in product development and design, opening up new applications on a new scale.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.0036 W
|
Low
|
0.0357 lm
|
0.007 cd
|
0.0695 mW
|
0.0136 mW/sr
|
160 °
|
-40 °C
|
100 °C
|
1.7 mm
|
0.8 mm
|
0.65 mm
|
|
OSRAM Mini TOPLED™, LY M67F
|
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.044 W
|
Low
|
2.32 lm
|
0.738 cd
|
4.83 mW
|
1.53 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
2.2 mm
|
1.4 mm
|
1.3 mm
|
|
OSRAM TOPLED™, LY T67F
|
First SMT LED with integrated reflector. With our great experience on SMT LED we are able to offer a high quality product for all kind of applications.
|
LEDs
|
Color LEDs
|
Yellow (580-595 nm)
|
0.044 W
|
Low
|
2.92 lm
|
0.925 cd
|
5.6 mW
|
1.78 mW/sr
|
120 °
|
-40 °C
|
100 °C
|
3.2 mm
|
2.8 mm
|
1.9 mm
|
AEC-Q102
|
|
OSRAM OSCONIQ™ P 3737 (2W), GR PUSRA2.25
|
Brand new, upgraded high-power LED with our ams OSRAM’s latest chip technology and new generation of optimized lens, delivering industry leading performance, superior robustness and long lifetime. With high efficiency REDS available in three wavelengths, the family offers five colors for ease of design and high flexibility for all your horticulture spectrum needs.
|
LEDs
|
Color LEDs
|
Red (612-630 nm)
|
1.4 W
|
High
|
29 lm
|
8.23 cd
|
888 mW
|
252 mW/sr
|
125 °
|
-40 °C
|
125 °C
|
3.7 mm
|
3.7 mm
|
2.37 mm
|
4.97 µmol/s
|
|
OSRAM OSRAM OSTAR™ Projection Power, LE D P1MS
|
OSRAM OSTAR Projection Power is a high luminance LED for projection applications.
|
LEDs
|
Color LEDs
|
Deep Blue (439-461 nm)
|
44.0 W
|
Ultra High
|
147 lm
|
47.8 cd
|
11400 mW
|
3690 mW/sr
|
120 °
|
7.6 mm
|
6.8 mm
|
1.4 mm
|
