Details
Parameters
Color of emission
Red (612-630 nm)
Electrical power
0.94
W
High
Brightness
ΦV
28.5
lm
IV
9.82
cd
ΦE
278
mW
IE
95.8
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
3.0
mm
w
3.0
mm
h
0.6
mm
Application fields
Ordering codes
Downloads
Tools
LightGuide
Calculate the effectiveness of an LED based on a selected light guide by showing the amount of incoupled, reflected and missed light rays.
Product selector
Find the right product.
More DURIS™ S 5
DURIS™ S 5 has it all: various white and color versions
