Details
Parameters
Color of emission
Deep Blue (439-461 nm)
Electrical power
0.29
W
Mid
Brightness
ΦV
5.5
lm
IV
1.88
cd
ΦE
166
mW
IE
56.8
mW/sr
Beam angle
∢
110
°
Operating temperature
Top
min.
-40
°C
Top
max.
120
°C
Dimension
l
2.6
mm
w
2.2
mm
h
1.25
mm
Application fields
